Eaton JGS325033G Molded Case Circuit Breaker – 250A – 3-Pole / 3-Phase – 600V – 85kA @ 240V / 40kA @ 415V / 35kA @ 480V / 18kA @ 600V – Metric Mounting Hardware – Series G JG

The Eaton JGS325033G is a 250A, 3-pole, 3-phase molded case circuit breaker from the Eaton Series G JG Frame. It features a 310+ electronic LS trip unit and is designed for compatible electrical distribution and circuit protection applications.

The breaker is rated for 600V and provides interrupting ratings of 85kAIC at 240V, 40kAIC at 415V, 35kAIC at 480V, and 18kAIC at 600V. It includes standard line- and load-side connections and metric mounting hardware.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Series G
• Series: Series G
• Frame: JG Frame
• Catalog No.: JGS325033G
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 85kAIC @ 240V; 40kAIC @ 415V; 35kAIC @ 480V; 18kAIC @ 600V
• Trip Unit: 310+ Electronic LS
• Trip Functions: Long-Time and Short-Time
• Connection: Standard Line/Load
• Mounting Hardware: Metric
• Application: Electrical Distribution and Circuit Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): JGS325033G
• Catalog Number: JGS325033G
• Model: JGS325033G
• Product Family: Eaton Series G Molded Case Circuit Breakers
• Series: Series G
• Frame: JG
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 250A
• Trip Unit: 310+ Electronic LS
• UPC:782116017980

Compatibility:

Designed for compatible Eaton Series G JG Frame electrical distribution equipment supporting Series G molded case circuit breakers with the applicable 310+ electronic LS trip unit. The JGS325033G provides 250A, 3-pole protection for compatible systems up to 600V.

The breaker includes standard line- and load-side connections and metric mounting hardware. Always verify the specific panelboard or electrical equipment model, system voltage, available fault current, trip-unit configuration, pole requirements, connection arrangement, mounting hardware, and installation requirements before installation.

Certifications:

• Eaton Series G
• JG Frame
• 250A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 85kAIC @ 240V
• 40kAIC @ 415V
• 35kAIC @ 480V
• 18kAIC @ 600V
• 310+ Electronic LS Trip Unit
• Long-Time and Short-Time Protection
• Standard Line/Load Connections
• Metric Mounting Hardware
