Square D JJL36250 Molded Case Circuit Breaker – 250A – 3-Pole / 3-Phase – 600V – 65kA @ 480V – Feed-Thru – PowerPact JJL Series

The Square D JJL36250 is a 250A, 3-pole, 3-phase molded case circuit breaker from the Square D PowerPact Type JJL Series. It features thermal-magnetic protection with Long-Time and Instantaneous (LI) trip functions and a non-interchangeable trip.

The JJL36250 is rated for 600V and provides a 65kA interrupting rating at 480V. It features a current-limiting design, feed-thru configuration, and line-side and load-side lug terminals. The breaker is UL Listed and suitable for reverse-fed applications.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: JJL
• Type: JJL
• Catalog No.: JJL36250
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Type: Non-Interchangeable
• Current Limiting: Current Limiting
• Mounting / Configuration: Feed-Thru
• Reverse Feed: Suitable for Reverse-Fed Applications
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): JJL36250
• Catalog Number: JJL36250
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: JJL
• Type: JJL
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Model: JJL36250
• Breaker Configuration: 3-Pole, 250A
• UPC:785901955979

Compatibility:

Designed for use with compatible Square D PowerPact JJL Series electrical distribution equipment that accepts feed-thru molded case circuit breakers. The JJL36250 is a 3-pole, 250A, 600V thermal-magnetic breaker with a 65kA interrupting rating at 480V and current-limiting construction.

The breaker features non-interchangeable Long-Time and Instantaneous (LI) trip functions, line-side and load-side lug terminals, and is suitable for reverse-fed applications.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip-unit requirements, terminal arrangement, reverse-feed requirements, and mounting configuration before installation.

Certifications:

• UL Listed
• PowerPact JJL Series
• 250A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• Current Limiting
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip Functions
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Suitable for Reverse-Fed Applications
• Line-Side and Load-Side Lug Terminals
