– 3-Pole / 3-Phase – 600V – 65kA @ 480V – Feed-Thru – PowerPact JJL Series

The Square D JJL36250U31X is a 250A, 3-pole, 3-phase molded case circuit breaker from the Square D / Schneider Electric PowerPact Type JJL Series. It features solid-state electronic protection with a MicroLogic Standard non-interchangeable trip unit and Long-Time and Instantaneous (LI) trip functions.

The breaker is rated for 600V and provides a 65kA interrupting rating at 480V. It features current-limiting construction, a feed-thru configuration, and line- and load-side lug terminals. It is suitable for reverse-fed applications and is identified as suitable for 2-pole applications. The breaker is UL Listed.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: JJL
• Type: JJL
• Catalog No.: JJL36250U31X
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Protection Type: Solid-State Electronic
• Trip Unit: MicroLogic Standard, Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Current Limiting: Current Limiting
• Mounting / Connection: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• 2-Pole Application: Suitable for 2-Pole Applications
• Reverse Feed: Suitable for Reverse-Fed Applications
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification

• Manufacturer Part Number (MPN): JJL36250U31X
• Catalog Number: JJL36250U31X
• Model: JJL36250U31X
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: JJL
• Type: JJL
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 250A
• Trip Configuration: MicroLogic Standard, Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• UPC:785901148371

Compatibility

Designed for use with compatible Square D / Schneider Electric PowerPact JJL Series electrical distribution equipment that accepts JJL Series molded case circuit breakers. The JJL36250U31X provides 250A, 3-pole protection for compatible 600V electrical distribution applications.

The breaker features current-limiting construction, a feed-thru configuration, MicroLogic Standard non-interchangeable trip unit, and line- and load-side lug terminals. It is suitable for reverse-fed applications and is identified as suitable for 2-pole applications.

Always verify the specific panelboard or electrical equipment model, approved breaker configuration, system voltage, available fault current, trip-unit requirements, pole configuration, terminal arrangement, and installation requirements before installation.

Certifications

• UL Listed
• PowerPact JJL Series
• 250A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• Solid-State Electronic Protection
• MicroLogic Standard Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip Functions
• Current Limiting
• Feed-Thru Configuration
• Line- and Load-Side Lug Terminals
• Suitable for Reverse-Fed Applications
• Suitable for 2-Pole Applications
