Square D LCL36400 400 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 65 kA@480 V – Feed-Thru – PowerPact Series

The Square D LCL36400 is a 400 Amp, 3-pole, 3-phase thermal-magnetic molded case circuit breaker from the Square D PowerPact LCL Series. It is rated for 600 V with a 65 kA interrupting rating at 480 V and features extra high interrupting capacity. The breaker is designed for feed-thru applications and includes LI (Long-Time and Instantaneous) trip functions with line and load-side lug terminals.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: LCL
• Type: LCL
• Catalog Number / MPN: LCL36400
• Primary Rating: 400 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 65 kA @ 480 V
• Interrupting Capacity: Extra High
• Trip Type: Thermal-Magnetic
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: LCL36400
• Series: LCL
• Type: LCL
• Current Rating: 400 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals
• UPC: 785901700722

Compatibility

The Square D LCL36400 is designed for compatible Square D PowerPact LCL Series electrical distribution applications.
