KDB2150
The Cutler Hammer KDB2150 is a Molded Case Circuit Breaker. This type KDB circuit breaker is a member of The Series C family. The KDB2150 is a 2 pole, 600 Volt, 150 amp rated circuit breaker, with an AIC rating of 35kA@480V. The KDB2150 is manufactured by Westinghouse. The KDB2150 uses a Feed-Thru connection. Includes Thermal Magnetic protection
Specifications
- Part Number: KDB2150
- Manufacturer : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : KDB
- Voltage : 600
- Amperage : 150
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679349229
- GTIN : 00786679349229
- Country of Origin : Dominican Republic
- Dimensions : Length 4.1in Height 5.5in Width 5.5in
- Weight : 11.5
- Certification : UL Listed
- Type Circuit Breakers
- Vendor Eaton Cutler-Hammer
- Brand Eaton
- Electrical Rating Feed Thru - 150 Amp - 2 Pole - 600 Volt
