Schneider Electric

Square D KDL32100 Molded Case Circuit Breaker – 100 Amp – 3-Pole – 240 Volt – Feed-Through – K-Frame

In stock
SKU: KDL32100 GTIN/UPC: 47569522291
$1,028.50
Sale $2,123.00 $1,028.50

Select product condition:

Condition
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
10 day returns

Ask an expert

Email 866-972-6370

The Square D KDL32100 is a 100 Amp, 3-pole molded case circuit breaker rated for 240 volts. It features a feed-through connection configuration.

Specifications

  • Manufacturer: Schneider Electric
  • Brand: Square D
  • Product Type: Molded Case Circuit Breaker (MCCB)
  • Part Number / MPN: KDL32100
  • Product Family: PowerPact K-Frame
  • Breaker Type: KDL
  • Frame Size: 250 Amp
  • Primary Rating: 100 Amp
  • Poles / Configuration: 3 Pole
  • Voltage: 240 Volt AC
  • Interrupting Capacity: 25 kA at 240 V
  • Connection: Feed-Through
  • Terminal Connection: Line and Load Lugs
  • Protection: Thermal Magnetic
  • Trip Functions: LI – Long-Time and Instantaneous
  • Magnetic Hold Current: 1,100 A
  • Magnetic Trip Current: 1,700 A
  • Wire Range: 6 AWG–350 kcmil Aluminum/Copper
  • Lug Kit: AL250KD
  • Mounting: Unit Mount
  • Series: K-Frame

Part Numbers & Identification

  • Manufacturer: Schneider Electric
  • Brand: Square D
  • Catalog Number: KDL32100
  • MPN: KDL32100
  • Breaker Type: KDL
  • Product Family: PowerPact K-Frame
  • Frame Rating: 250 A
  • Current Rating: 100 A
  • Pole Count: 3 Pole
  • Voltage Rating: 240 V
  • Interrupting Rating: 25 kA at 240 V
  • Connection Configuration: Feed-Through
  • Replacement Lug Kit: AL250KD
  • UPC:785901078760

Compatibility

The Square D KDL32100 is designed for compatible Square D K-Frame circuit breaker applications and I-Line panelboard installations.

  • Compatible Panelboards: Square D I-Line panelboards
  • Compatible Frame Family: PowerPact K-Frame
  • Compatible Lug Kit: AL250KD (100–250 Amp KDL/KGL breakers)
  • Related Breaker Type: KGL
  • Type Circuit Breakers
  • Vendor Schneider Electric
  • Brand Square D
  • Electrical Rating Feed Thru - 100 Amp - 3 Pole - 240 Volt
