Square D EDB36090 Molded Case Circuit Breaker – 90A – 3-Pole / 3-Phase – 600Y/347V AC –EDB Series

The Square D EDB36090 is a 90A, 3-pole, 3-phase molded case circuit breaker from the Square D EDB Series. It is designed for compatible electrical distribution and overcurrent protection applications.

The EDB36090 features thermal-magnetic protection and a bolt-on mounting configuration for compatible Square D electrical distribution equipment. It is rated for 600Y/347V AC and is designed for applications requiring reliable branch-circuit overcurrent protection.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: EDB
• Series: EDB
• Catalog No.: EDB36090
• Current Rating: 90A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600Y/347V AC
• Protection Type: Thermal-Magnetic
• Mounting / Connection: Bolt-On
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EDB36090
• Catalog Number: EDB36090
• Model: EDB36090
• Product Family: Square D EDB Circuit Breakers
• Series: EDB
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 90A
• Rated Current: 90A
• Rated Voltage: 600Y/347V AC
• UPC:785901241737

Compatibility:

Designed for use with compatible Square D / Schneider Electric EDB Series electrical distribution equipment that accepts EDB Series bolt-on molded case circuit breakers. The EDB36090 provides 90A, 3-pole thermal-magnetic overcurrent protection for compatible 600Y/347V AC electrical distribution applications.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, mounting arrangement, terminal requirements, and installation specifications before installation.

Certifications:

• EDB Series
• 90A Rated
• 3-Pole / 3-Phase
• 600Y/347V AC Rated
• Thermal-Magnetic Protection
• Bolt-On Mounting
