Square D LA36175 175 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC / 250 V DC – 30 kA@480 V AC – I-Line Plug-In – Type LA

The Square D LA36175 is a 175 Amp, 3-pole, 3-phase molded case circuit breaker from the Square D I-Line Series, Type LA. It provides thermal-magnetic protection with LI (Long-Time and Instantaneous) trip functions and is rated for 600 V AC and 250 V DC. The breaker features a 30 kA interrupting rating at 480 V AC and is designed for I-Line panelboard applications with an I-Line plug-in connection and load-side lug terminals.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: I-Line
• Type: LA
• Frame: LA / L-Frame
• Catalog Number / MPN: LA36175
• Primary Rating: 175 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Phase Connection: ABC
• Voltage: 600 V AC
• DC Voltage: 250 V DC
• Interrupting Rating: 30 kA @ 480 V AC
• Trip Type: Thermal-Magnetic
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: I-Line Plug-In
• Terminals: Load-Side Lug Terminals
• Actuator: Toggle Handle
• Wire Size: 1 AWG to 600 kcmil, Single Conductor; 1 AWG to 250 kcmil, Two Conductors
• Temperature Rating: 40°C
• Weight: Approximately 10 lb
• Dimensions (H × W × D): 11" × 6" × 5.84"

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: LA36175
• Series: I-Line
• Type: LA
• Frame: LA / L-Frame
• Current Rating: 175 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: I-Line Plug-In
• Terminals: Load-Side Lug Terminals
• UPC: 785901339281
• Country of Origin: Mexico

Compatibility

The Square D LA36175 is designed for compatible Square D I-Line panelboard applications.

Certifications

• UL Listed
• CSA Certified
