Leviton LB245-T: 45A 2P 120/240V Standard Plug-On Neutral Circuit Breaker

The Leviton LB245-T is a 45 Amp, 2-Pole standard thermal magnetic breaker designed for safe and reliable residential and light commercial circuit protection. With plug-on neutral installation, it provides convenient operation and robust protection.

Electrical Ratings

• Amperage: 45 Amps
• Voltage Rating: 120/208V, 120/240V AC
• Number of Poles: 2-Pole
• Interrupt Rating: 10 kAIC

Design & Construction

• Breaker Type: Standard Thermal Magnetic Circuit Interrupter
• Mounting Mode: Plug-in
• Connections Terminals: Plug-on neutral
• Wire Size Compatibility: (1) #14–4 AWG Cu/Al
• Tightening Torque: 35.4 lb-in

Physical Specifications

• Height: 3.9 inches
• Width: 2.0 inches
• Depth: 3.1 inches
• Weight: 0.794 lbs

Certifications

• UL Listed
• RoHS Compliant

Product Information

• Manufacturer: Leviton Manufacturing Co., Inc.
• Brand: Leviton
• Product Range: Leviton Load Centers (for Leviton loadcenters and equipment)
• Model Number: LB245-T
• UPC: 078477644713

The Leviton LB245-T plug-on neutral circuit breaker provides reliable 45A, 2-pole thermal magnetic protection for 120/208V and 120/240V circuits. With intuitive color indicators and a rocker-style switch, it ensures enhanced safety, convenience, and consistent performance for residential and light commercial applications.
