Leviton LB280 80A 2P Hydraulic-Magnetic Standard Circuit Breaker – Plug-On – 120/240V

The Leviton LB280 is a 2-pole hydraulic-magnetic plug-on circuit breaker designed for Leviton Smart Load Centers and compatible plug-on neutral panels. Providing 80A protection for 120/240V and 120/208V circuits, it features a 10kA interrupt rating and precise hydraulic-magnetic trip technology, delivering reliable overload and short-circuit protection while maintaining performance across extreme temperatures.

Electrical Ratings:

• Amperage: 80 Amps
• Poles: 2-Pole
• Voltage: 120/240V AC (also supports 120/208V)
• Interrupt Rating: 10 kAIC

Key Specifications:

• Breaker Type: Standard Thermal-Magnetic (Hydraulic-Magnetic Trip)
• Mounting Mode: Plug-On Neutral
• Connections Terminals: Plug-On Neutral
• Wire Size: #14–4 AWG Cu/Al
• Tightening Torque: 40 lb-in

Dimensions & Weight:

• • Height: 3.9 in
  • Width: 2.0 in
  • Depth: 3.1 in
  • Weight: 0.85 lbs

Certifications:

• UL Listed

Product Data:

• Manufacturer: Leviton Manufacturing Co., Inc.
• Brand: Leviton
• Product Range: Leviton Smart Load Center (compatible with plug-on neutral loadcenters)
• Model Number: LB280
• UPC: 078477814529
