Eaton Cutler-Hammer LGE3400AAG 400 Amp Molded Case Circuit Breaker – 3 Pole – 600 Vac – 65 kAIC at 240 Vac – Series G

The Eaton Cutler-Hammer LGE3400AAG is a Series G molded case circuit breaker featuring an LG frame, a 400 A current rating, and an adjustable thermal, adjustable magnetic trip mechanism. Designed for industrial and commercial electrical distribution systems, it provides adjustable thermal overload and magnetic short-circuit protection. The breaker has interrupting capacities of 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac. It supports 50/60 Hz operation, features line- and load-side connections, uses a metric configuration, and is rated for 80% continuous loading.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker (MCCB)
• Product Series: Series G
• Frame Type: LG Frame
• Breaker Type: LGE
• Catalog Number: LGE3400AAG
• Current Rating: 400 A
• Number of Poles: 3 Pole
• Voltage Rating: 600 Vac
• Interrupting Capacity at 240 Vac: 65 kAIC
• Interrupting Capacity at 480 Vac: 35 kAIC
• Interrupting Capacity at 600 Vac: 18 kAIC
• Trip Type: Adjustable thermal, adjustable magnetic
• Protection Functions: Thermal overload and magnetic short-circuit protection
• Connection Type: Line and load
• Frequency: 50/60 Hz
• Rated Load: 80% rated
• Measurement System: Metric

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: LGE3400AAG
• Product Family: Series G
• Frame Designation: LG Frame
• Breaker Configuration: Complete molded case circuit breaker
• Trip Mechanism: Adjustable thermal, adjustable magnetic
• Current Rating: 400 Amp
• Pole Configuration: 3 Pole
• UPC:782116120376

Compatibility

Designed for electrical distribution applications requiring an Eaton Cutler-Hammer Series G LG-frame, three-pole, 400 A molded case circuit breaker with adjustable thermal and adjustable magnetic trip functions. Compatibility depends on matching the electrical ratings, frame configuration, and installation requirements of the existing equipment.
