Eaton LGS3500AAG 500 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC – 25 kAIC@600 V – Adjustable Thermal-Magnetic Trip – Series G

The Eaton LGS3500AAG is a 500 Amp, 3-pole molded case circuit breaker from the Eaton / Cutler-Hammer Series G, LG-frame product family. It is rated for 600 V AC and features adjustable thermal and adjustable magnetic trip protection. The breaker provides interrupting ratings of 85 kAIC at 240 V AC, 50 kAIC at 415/480 V AC, and 25 kAIC at 600 V AC. This complete breaker supports line- and load-side connections and uses a metric terminal system.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series G
• Frame: LG Frame
• Catalog Number / MPN: LGS3500AAG
• Primary Rating: 500 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600 V AC
• Interrupting Rating: 85 kAIC @ 240 V AC; 50 kAIC @ 415/480 V AC; 25 kAIC @ 600 V AC
• Trip Type: Thermal-Magnetic
• Thermal Trip: Adjustable
• Magnetic Trip: Adjustable
• Assembly: Complete Breaker
• Connection: Line and Load
• Terminal System: Metric

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: LGS3500AAG
• Series: Series G
• Frame: LG Frame
• Current Rating: 500 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Thermal Trip: Adjustable
• Magnetic Trip: Adjustable
• Terminal System: Metric
• UPC:782116120505

Compatibility

The Eaton LGS3500AAG is designed for compatible Eaton Series G LG-frame electrical distribution applications.
