Square D LH36200 200 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC – 65 kA@240 V / 35 kA@480 V / 25 kA@600 V – Unit-Mount – LH Series

The Square D LH36200 is a 200 Amp, 3-pole molded case circuit breaker from the Square D LH Series. It provides thermal-magnetic protection with LI (Long-Time and Instantaneous) trip functions and is rated for 600 V AC. The breaker features high interrupting ratings of 65 kA at 240 V, 35 kA at 480 V, and 25 kA at 600 V. It is designed for unit-mount applications and includes lug terminals for copper/aluminum conductors.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: LH
• Type: LH
• Frame: LH
• Catalog Number / MPN: LH36200
• Primary Rating: 200 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V AC
• Interrupting Rating: 65 kA @ 240 V; 35 kA @ 480 V; 25 kA @ 600 V
• Trip Type: Thermal-Magnetic
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: Unit-Mount
• Terminals: Lug Terminals for Copper/Aluminum Conductors
• Actuator: Toggle Handle
• Temperature Rating: 40°C
• Weight: Approximately 12 lb
• Dimensions (H × W × D): 11" × 6" × 5.84"

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: LH36200
• Series: LH
• Type: LH
• Frame: LH
• Current Rating: 200 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: Unit-Mount
• Terminals: Lug Terminals for Copper/Aluminum Conductors
• UPC: 785901790280
• Country of Origin: Mexico

Compatibility

The Square D LH36200 is designed for compatible Square D LH Series panelboard applications.

Certifications

• UL Listed
• CSA Certified
