Littelfuse FLSR225ID Class RK5 Fuse – 225A – 600V Time-Delay Indicating Fuse

The Littelfuse FLSR225ID is a 225 Amp Class RK5 dual-element time-delay fuse designed for industrial and commercial electrical distribution systems. Part of the FLSR_ID series, this fuse incorporates a built-in blown-fuse indicator for quick visual status identification and simplified maintenance. Its dual-element construction allows temporary inrush currents associated with motors and transformers while providing reliable overload and short-circuit protection.

Electrical Rating

• Current Rating: 225 Amps
• Maximum AC Voltage: 600 VAC
• Maximum DC Voltage: 300 VDC
• Interrupting Rating:
  • 200 kA AC
  • 20 kA DC @ 300 VDC

Key Specifications

• Manufacturer: Littelfuse
• Catalog Number: FLSR225ID
• Series: FLSR_ID
• Fuse Class: RK5
• Construction Type: Knife-Blade
• Fuse Type: Dual Element Time-Delay
• Indicating: Yes

Protection Characteristics

• Time-delay (slow-blow) operation
• Dual-element fuse construction
• Provides overload and short-circuit protection
• Allows temporary motor starting and transformer inrush currents without nuisance opening
• High interrupting capacity for industrial power distribution systems

Construction Features

• Knife-blade terminal design
• Visual blown-fuse indication feature
• Industrial-duty construction for demanding applications
• Designed for reliable long-term service

Mounting & Compatibility

• Mounting Method: Fuse Block / Clip / Holder
• Compatible with standard Class RK5 fuse holders and fuse blocks
• Suitable for switchboards, panelboards, motor control centers, and industrial distribution equipment

Applications

• Motor branch circuit protection
• Transformer protection
• Industrial machinery and equipment
• Commercial electrical distribution systems
• Feeder and branch circuit protection

Product Data

• Manufacturer: Littelfuse
• Catalog Number: FLSR225ID
• Product Type: Indicating Time-Delay Fuse
• Series: FLSR_ID
• Fuse Class: RK5
