Littelfuse FLSR600 Class RK5 Fuse – 600A – 600V Time-Delay Fuse

The Littelfuse FLSR600 is a 600 Amp Class RK5 dual-element time-delay fuse designed for industrial and commercial electrical distribution systems. Part of the FLSR series, this knife-blade fuse provides reliable overload and short-circuit protection for motors, transformers, feeders, and other power distribution equipment. Its dual-element construction allows temporary motor starting and transformer inrush currents to pass without nuisance opening while maintaining dependable fault interruption performance.

Electrical Rating

• Current Rating: 600 Amps
• Maximum AC Voltage: 600 VAC
• Maximum DC Voltage: 300 VDC
• Interrupting Rating:
  • 200 kA AC
  • 20 kA DC @ 300 VDC

Key Specifications

• Manufacturer: Littelfuse
• Catalog Number: FLSR600
• Series: FLSR
• Fuse Class: RK5
• Construction Type: Knife-Blade
• Fuse Type: Dual Element Time-Delay
• Indicating: No

Protection Characteristics

• Time-delay (slow-blow) operation
• Dual-element fuse construction
• Provides overload and short-circuit protection
• Accommodates temporary motor starting and transformer inrush currents
• High interrupting capacity for industrial power distribution systems

Construction Features

• Knife-blade terminal design
• Non-indicating fuse configuration
• Industrial-duty construction for demanding applications
• Designed for reliable long-term service

Mounting & Compatibility

• Mounting Method: Fuse Block / Clip / Holder
• Compatible with standard Class RK5 fuse holders and fuse blocks
• Suitable for switchboards, panelboards, motor control centers, and industrial distribution equipment

Applications

• Motor branch circuit protection
• Transformer protection
• Industrial machinery and equipment
• Commercial electrical distribution systems
• Feeder and branch circuit protection

Product Data

• Manufacturer: Littelfuse
• Catalog Number: FLSR600
• Product Type: Time-Delay Fuse
• Series: FLSR
• Fuse Class: RK5
