Siemens LMXD63A800 800 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 50 kA@480 V – Bolt-On – SENTRON Series

The Siemens LMXD63A800 is an 800 Amp, 3-pole molded case circuit breaker from the Siemens SENTRON Series, Type LMXD. It is rated for 600 V with a 50 kA interrupting rating at 480 V and features standard interrupting capacity. The breaker is a magnetic-only motor circuit protector with instantaneous (I) protection, a standard instantaneous range, and a magnetic range of 3200–8000 A. It is designed for bolt-on mounting.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Molded Case Circuit Breaker
• Series: SENTRON
• Type: LMXD
• Catalog Number / MPN: LMXD63A800
• Primary Rating: 800 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 50 kA @ 480 V
• Interrupting Capacity: Standard
• Trip Type: Magnetic Only
• Trip Functions: I – Instantaneous Only
• Instantaneous Range: Standard
• Magnetic Range: 3200–8000 A
• Connection / Mounting: Bolt-On
• Application: Motor Circuit Protector (MCP)

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: LMXD63A800
• Series: SENTRON
• Type: LMXD
• Current Rating: 800 A
• Pole Count: 3 Pole
• Product Type: Magnetic-Only Molded Case Circuit Breaker / Motor Circuit Protector
• Trip Function: I – Instantaneous Only
• Instantaneous Range: Standard
• Magnetic Range: 3200–8000 A
• UPC:783643302594

Compatibility

The Siemens LMXD63A800 is designed for compatible Siemens SENTRON Type LMXD motor circuit protector and motor starter applications.
