Siemens LMXD63A800 800 Amp Motor Circuit Protector – 3 Pole – 600 V – 50 kA@480 V – Bolt-On – SENTRON Series

The Siemens LMXD63A800 is an 800 Amp, 3-pole motor circuit protector (MCP) from the Siemens SENTRON Series, Type LMXD. Designed for motor protection applications, it provides magnetic-only protection with instantaneous trip functionality. The breaker has a 50 kA interrupting rating at 480 V and a standard instantaneous trip range. It is designed for bolt-on mounting and has a magnetic adjustment range of 3200–8000 A.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Motor Circuit Protector (MCP)
• Series: SENTRON
• Type: LMXD
• Catalog Number / MPN: LMXD63A800
• Primary Rating: 800 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 50 kA @ 480 V
• Interrupting Capacity: Standard
• Trip Type: Magnetic Only
• Trip Functions: I – Instantaneous Protection Only
• Instantaneous Range: Standard
• Magnetic Range: 3200–8000 A
• Connection / Mounting: Bolt-On

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: LMXD63A800
• Series: SENTRON
• Type: LMXD
• Current Rating: 800 A
• Pole Count: 3 Pole
• Product Type: Motor Circuit Protector (MCP)
• Trip Type: Magnetic Only
• Trip Function: I – Instantaneous Protection Only
• Magnetic Range: 3200–8000 A
• Connection: Bolt-On
• UPC:783643302594

Compatibility

The Siemens LMXD63A800 is intended for compatible Siemens SENTRON Type LMXD motor protection and electrical distribution applications.
