Mersen 62001R 200A 1-Pole Class R Fuse Block – Box Style – Side-Clip Design – 600VAC/600VDC

The Mersen 62001R is a heavy-duty 1-pole fuse block designed for Class R fuse applications in industrial and commercial electrical distribution systems. Rated at 200A, this fuse block features a side-clip design that ensures secure fuse retention and reliable electrical contact under high-load and fault conditions. With a voltage rating of 600VAC and 600VDC, it is suitable for feeder circuits, branch circuits, and high-capacity equipment protection requiring robust current-limiting fuse coordination.

Voltage and Rating

• Current Rating: 200 Amps
• Voltage Rating: 600VAC / 600VDC
• Frequency: 50/60 Hz
• Fuse Class Compatibility: Class R
• Number of Poles: 1

Key Specifications

• Product Type: Fuse Block
• Part Number: 62001R
• Manufacturer: Mersen / Ferraz Shawmut
• Mounting Style: Box Mount
• Connector Type: Side-Clip Design
• Phase Compatibility: Single-pole applications
• Application Type: Industrial power distribution systems

Technical Specifications

• Construction Material: High-dielectric thermoplastic insulation housing
• Contact Material: Tin-plated copper clips for high conductivity and corrosion resistance
• Clip Design: Side-clip system for enhanced mechanical stability and fuse retention
• Wiring Compatibility: Suitable for copper conductors depending on terminal configuration
• Thermal Performance: Designed for continuous duty at rated current

Standards and Approvals

• UL Listed component for Class R fuse systems
• CSA Certified
• Designed for industrial-grade fuse protection applications

Product Data

• Manufacturer: Mersen / Ferraz Shawmut
• Part Number: 62001R
• EAN/UPC: 782001750336
• Series: Class R Fuse Block Series

Applications

• Industrial control panels
• Motor control centers (MCCs)
• Feeder circuit protection
• Branch circuit protection
• Heavy-duty equipment protection
• Commercial electrical distribution systems
• Retrofit and maintenance fuse assemblies
