Eaton NGC308033E 800 Amp Molded Case Circuit Breaker – 3 Pole – 480 V – 200 kA@240 V – 100 kA@480 V – Electronic LS – Series G

The Eaton NGC308033E is an 800 Amp, 3-pole electronic molded case circuit breaker from Eaton's Series G. It uses an NG-frame with a Digitrip 310 RMS electronic LS trip unit and is rated for 480 Vac. The breaker provides 200 kA interrupting capacity at 240 Vac and 100 kA at 480 Vac. It is line- and load-connected, designed for 50/60 Hz applications, and is 80% rated.

Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Product Type: Molded Case Circuit Breaker
• Series: Series G
• Frame: NG
• Catalog Number / MPN: NGC308033E
• Primary Rating: 800 Amp
• Poles / Configuration: 3 Pole
• Voltage: 480 Vac
• Frequency: 50/60 Hz
• Interrupting Rating: 200 kA @ 240 Vac; 100 kA @ 480 Vac
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic
• Trip Functions: LS – Long-Time and Short-Time
• Connection: Line and Load
• Rating: 80% Rated
• Frame Type: NG

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton
• Catalog Number: NGC308033E
• Series: Series G
• Frame: NG
• Current Rating: 800 A
• Pole Count: 3 Pole
• Trip Unit: Digitrip 310 RMS
• Trip Type: Electronic LS
• Frequency: 50/60 Hz
• UPC: 786685379012

Compatibility

The Eaton NGC308033E is designed for compatible Eaton Series G NG-frame electrical distribution applications. Verify the specific panelboard or switchboard, system voltage, mounting configuration, and breaker compatibility before installation.
