Eaton NGC312035E Molded Case Circuit Breaker – 1200A – 3-Pole / 3-Phase – 480V AC – 200kAIC @ 240V / 100kAIC @ 480V – Line & Load – Series G NG Frame

The Eaton NGC312035E is a 1200A, 3-pole, 3-phase electronic molded case circuit breaker from the Eaton Series G NG Frame. It features a Digitrip 310 RMS electronic trip unit with Long-Time, Short-Time, and Ground-Fault (LSG) trip functions.

The breaker is rated for 480V AC and provides interrupting ratings of 200kAIC at 240V AC and 100kAIC at 480V AC. It features line- and load-side connections, an imperial configuration, 50/60 Hz operation, and is 80% rated.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Electronic Molded Case Circuit Breaker
• Product Family: Series G
• Series: Series G
• Frame: NG Frame
• Type: NG
• Catalog No.: NGC312035E
• Current Rating: 1200A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V AC
• Frequency: 50/60 Hz
• Trip Unit: Digitrip 310 RMS
• Protection Type: Electronic
• Trip Functions: Long-Time, Short-Time, and Ground-Fault (LSG)
• Interrupting Rating: 200kAIC @ 240V AC; 100kAIC @ 480V AC
• Connection: Line and Load
• Measurement / Configuration: Imperial
• Rated Duty: 80% Rated
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): NGC312035E
• Catalog Number: NGC312035E
• Model: NGC312035E
• Product Family: Eaton Series G Molded Case Circuit Breakers
• Series: Series G
• Frame: NG Frame
• Type: NG
• Brand: Eaton
• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Electronic Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 1200A
• Trip Unit: Digitrip 310 RMS
• Trip Configuration: Long-Time, Short-Time, Ground-Fault (LSG)
• UPC:786685379111

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series G NG-frame electrical distribution equipment that accepts NG-frame electronic molded case circuit breakers. The NGC312035E provides 1200A, 3-pole electronic protection for compatible 480V AC electrical distribution applications.

The breaker uses a Digitrip 310 RMS electronic LSG trip unit and provides line- and load-side connections. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, trip-unit compatibility, pole configuration, connection requirements, 80% rating requirements, and installation specifications before installation.

Certifications:

• Series G
• NG Frame
• 1200A Rated
• 3-Pole / 3-Phase
• 480V AC Rated
• 200kAIC @ 240V AC Interrupting Rating
• 100kAIC @ 480V AC Interrupting Rating
• Digitrip 310 RMS
• Electronic LSG Trip
• Long-Time Protection
• Short-Time Protection
• Ground-Fault Protection
• Line and Load Connections
• 50/60 Hz
• 80% Rated
