Eaton PDG23F0020TFFJ Molded Case Circuit Breaker – 20A – 3-Pole / 3-Phase – 480V – 25kA – Thermal-Magnetic Fixed-Fixed – Power Defense Frame 2

The Eaton PDG23F0020TFFJ is a 20A, 3-pole molded case circuit breaker from the Eaton Power Defense Frame Size 2 family. It features a fixed-fixed thermal-magnetic (T-M) trip unit and provides a 25kA interrupting rating at 480V.

Power Defense Frame Size 2 breakers cover a range of 15A through 225A and are configured with a trip unit from the factory. The product family is designed for a wide range of circuit protection and power distribution applications, with available options including PXR electronic trip units, ground-fault protection, current limiting, energy metering, communication capabilities, breaker health indication, and zone selective interlocking.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Power Defense
• Frame Size: Frame 2
• Catalog No.: PDG23F0020TFFJ
• Alternate / Related Model: PDG2X3T100
• Current Rating: 20A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V
• Interrupting Rating: 25kA @ 480V
• Protection Type: Thermal-Magnetic
• Trip Unit: Fixed-Fixed Thermal-Magnetic (T-M)
• Trip Configuration: Fixed-Fixed
• Breaker Configuration: Factory-Configured Trip Unit
• Frame Current Range: 15–225A
• Application: Circuit Protection and Power Distribution
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): PDG23F0020TFFJ
• Catalog Number: PDG23F0020TFFJ
• Model: PDG23F0020TFFJ
• Product Family: Eaton Power Defense
• Frame: Frame 2
• Related Model: PDG2X3T100
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 20A
• Trip Configuration: Fixed-Fixed Thermal-Magnetic
• UPC:786679282489

Compatibility:

Designed for compatible Eaton Power Defense Frame Size 2 electrical distribution and circuit protection applications. Frame Size 2 breakers are available from 15A through 225A with factory-configured trip units and modular accessories that can be field-installed or factory-configured.

The Power Defense family also offers PXR electronic trip units and optional protection and monitoring capabilities, depending on the specific breaker configuration. Always verify the specific breaker model, system voltage, available fault current, trip-unit configuration, accessories, and installation requirements before installation.

Certifications:

• Eaton Power Defense
• Frame Size 2
• 20A Rated
• 3-Pole / 3-Phase
• 25kA @ 480V Interrupting Rating
• Thermal-Magnetic Protection
• Fixed-Fixed Trip Unit
• Factory-Configured Trip Unit
• 15–225A Frame Size Range
