Eaton PDG23G0040TFFJ 40 Amp Molded Case Circuit Breaker – 3 Pole – 35 kA@480 V – Frame 2 – Power Defense Series

The Eaton PDG23G0040TFFJ is a 40 Amp, 3-pole molded case circuit breaker from the Eaton Power Defense series. It features a globally rated Frame 2 design and a fixed thermal-magnetic trip unit with fixed thermal and fixed magnetic settings. The breaker provides a 35 kA interrupting rating at 480 V and includes standard line and load terminals for compatible electrical distribution applications.

Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Product Type: Molded Case Circuit Breaker
• Series: Power Defense
• Frame Size: Frame 2
• Catalog Number / MPN: PDG23G0040TFFJ
• Primary Rating: 40 Amp
• Poles / Configuration: 3 Pole
• Interrupting Rating: 35 kA @ 480 V
• Trip Type: Thermal-Magnetic
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Terminals: Standard Line & Load Terminals
• Rating Type: Globally Rated

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton
• Catalog Number: PDG23G0040TFFJ
• Series: Power Defense
• Frame Size: Frame 2
• Current Rating: 40 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Unit Configuration: Fixed-Fixed
• UPC:786679244524

Compatibility

The Eaton PDG23G0040TFFJ is intended for compatible Eaton Power Defense Frame 2 electrical distribution and circuit protection applications.
