Eaton PDG23G0080TFFJ Molded Case Circuit Breaker – 80A – 3-Pole / 3-Phase – 480V – 35kA – Globally Rated – Power Defense PDG Series

The Eaton PDG23G0080TFFJ is an 80A, 3-pole molded case circuit breaker from the Eaton Power Defense Frame Size 2 Series. It is a globally rated breaker configured with a fixed-fixed thermal-magnetic (T-M) trip unit and standard line- and load-side connections.

The breaker is rated at 35kA at 480V and is designed for compatible circuit protection and power distribution applications. Frame Size 2 covers circuit breaker ratings from 15A through 225A and supports a range of factory-configured trip units and modular accessories.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Power Defense
• Series: Power Defense PDG
• Frame Size: Frame 2
• Catalog No.: PDG23G0080TFFJ
• Current Rating: 80A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V
• Interrupting Rating: 35kA @ 480V
• Rating Type: Globally Rated
• Trip Technology: Thermal-Magnetic
• Trip Configuration: Fixed-Fixed (T-M)
• Trip Unit: Thermal-Magnetic Fixed-Fixed Trip Unit
• Line Connection: Standard
• Load Connection: Standard
• Trip Unit Configuration: Factory Configured
• Accessories: Modular Accessories Available
• Application: Circuit Protection and Power Distribution
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): PDG23G0080TFFJ
• Catalog Number: PDG23G0080TFFJ
• Model: PDG23G0080TFFJ
• Product Family: Eaton Power Defense Molded Case Circuit Breakers
• Series: Power Defense PDG
• Frame: Frame Size 2
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 80A
• Trip Configuration: Fixed-Fixed Thermal-Magnetic
• Rating Type: Globally Rated
• UPC:786679244531

Compatibility:

Designed for use with compatible Eaton Power Defense Frame Size 2 electrical distribution equipment supporting PDG Series molded case circuit breakers. Frame Size 2 breakers are available in ratings from 15A through 225A and can be configured with thermal-magnetic or PXR electronic trip units, depending on the model.

The PDG23G0080TFFJ is an 80A, 3-pole, 480V thermal-magnetic breaker with a 35kA interrupting rating at 480V and factory-configured fixed-fixed trip protection. Modular accessories may be field-installed or factory-configured where applicable.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, trip-unit configuration, terminal arrangement, accessory requirements, and installation specifications before installation.

Certifications:

• Eaton Power Defense Series
• Frame Size 2
• 80A Rated
• 3-Pole / 3-Phase
• 480V Rated
• 35kA @ 480V Interrupting Rating
• Globally Rated
• Thermal-Magnetic Protection
• Fixed-Fixed Trip Configuration
• Standard Line and Load Connections
• Factory-Configured Trip Unit
• Modular Accessories Available
