Square D QBL32250 Molded Case Circuit Breaker – 250A – 3-Pole / 3-Phase – 240V – 10kA @ 240V – Feed-Thru – PowerPact QBL Series

The Square D QBL32250 is a 250A, 3-pole, 3-phase molded case circuit breaker from the Square D / Schneider Electric PowerPact Type QBL Series. It features thermal-magnetic protection with a non-interchangeable trip and Long-Time and Instantaneous (LI) trip functions.

The QBL32250 is rated for 240V and provides a 10kA interrupting rating at 240V with standard interrupting capacity. It features a feed-thru configuration, line-side and load-side lug terminals, and is supplied as a complete breaker.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: QBL
• Type: QBL
• Catalog No.: QBL32250
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 240V
• Interrupting Rating: 10kA @ 240V
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Breaker Configuration: Complete Breaker
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): QBL32250
• Catalog Number: QBL32250
• Model: QBL32250
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: QBL
• Type: QBL
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 250A
• Trip Configuration: Non-Interchangeable LI
• UPC:785901907237

Compatibility:

Designed for use with compatible Square D / Schneider Electric PowerPact QBL Series electrical distribution equipment that accepts QBL Series molded case circuit breakers. The QBL32250 provides 250A, 3-pole thermal-magnetic overcurrent protection for compatible 240V electrical distribution applications.

The breaker features a non-interchangeable trip, LI Long-Time and Instantaneous trip functions, feed-thru configuration, and line-side and load-side lug terminals. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip-unit requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• UL Listed
• PowerPact QBL Series
• 250A Rated
• 3-Pole / 3-Phase
• 240V Rated
• 10kA @ 240V Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip Functions
• Feed-Thru Configuration
• Line-Side and Load-Side Lug Terminals
• Complete Breaker
