Square D QDA32200 Molded Case Circuit Breaker – 200A – 3-Pole – 240V AC – 25kA @ 240V AC – I-Line Plug-In – QDA Series

The Square D QDA32200 is a 200A, 3-pole molded case circuit breaker from the Square D I-Line QDA Series. It is designed for compatible electrical distribution applications and features an I-Line style plug-in connection.

The breaker has a 240V AC voltage rating and a 25kA interrupting rating at 240V AC. It features thermal-magnetic protection, a non-interchangeable trip, and Long-Time and Instantaneous (LI) trip functions. The breaker includes load-side lug terminals and is configured for ABC phase connection.

Specifications:

• Manufacturer: Schneider Electric / Square D
• Product Type: Molded Case Circuit Breaker
• Catalog No.: QDA32200
• Product Family: I-Line
• Series: QDA
• Current Rating: 200A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Phase Connection: ABC
• Voltage Rating: 240V AC
• Interrupting Rating: 25kA @ 240V AC
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: I-Line Style Plug-In
• Terminal Type: Load-Side Lug Terminals
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D

Part Numbers & Identification:

• Manufacturer Part Number (MPN): QDA32200
• Catalog Number: QDA32200
• Model: QDA32200
• Product Family: Square D I-Line Circuit Breakers
• Series: QDA
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 200A
• Trip Configuration: Non-Interchangeable LI
• upc:785901417842

Compatibility:

Designed for use with compatible Square D I-Line QDA Series electrical distribution equipment that accepts I-Line style plug-in molded case circuit breakers. The QDA32200 provides 200A, 3-pole protection for compatible 240V AC electrical distribution applications.

The breaker features thermal-magnetic LI protection, a non-interchangeable trip, and load-side lug terminals. Always verify the specific panelboard model, approved breaker type, system voltage, available fault current, pole configuration, I-Line compatibility, terminal arrangement, and installation requirements before installation.

Certifications:

• UL Listed
• 200A Rated
• 3-Pole / 3-Phase
• 240V AC Rated
• 25kA @ 240V AC Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip
• I-Line Style Plug-In
• Load-Side Lug Terminals
• Square D QDA Series
