Siemens QRH23B200 Molded Case Circuit Breaker – 200A – 3-Pole / 3-Phase – 240V – 25kA @ 240V – Bolt-On – QR Series

The Siemens QRH23B200 is a 200A, 3-pole, 3-phase molded case circuit breaker from the Siemens QR Series, Type QRH2. It features thermal-magnetic protection with Long-Time and Instantaneous (LI) trip functions and a non-interchangeable trip.

The QRH23B200 is rated for 240V and provides a 25kA interrupting rating at 240V, with high interrupting capacity. It uses a bolt-on connection, includes load-side lug terminals, and is designed for compatible Siemens electrical distribution equipment.

Specifications:

• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Product Family: QR Series
• Series: QR
• Type: QRH2
• Catalog No.: QRH23B200
• Current Rating: 200A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 240V
• Interrupting Rating: 25kA @ 240V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Type: Non-Interchangeable
• Connection / Mounting: Bolt-On
• Terminal Type: Load-Side Lug Terminals
• Application: Electrical Distribution and Overcurrent Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): QRH23B200
• Catalog Number: QRH23B200
• Model: QRH23B200
• Product Family: Siemens QR Circuit Breakers
• Series: QR
• Type: QRH2
• Brand: Siemens
• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 200A
• UPC:804766136801

Compatibility:

Designed for use with compatible Siemens QR Series electrical distribution equipment that accepts QRH2 bolt-on molded case circuit breakers. The QRH23B200 provides 200A, 3-pole thermal-magnetic protection for compatible 240V, 3-phase applications and features a 25kA interrupting rating at 240V.

The breaker includes load-side lug terminals and a non-interchangeable LI trip. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, terminal arrangement, and installation requirements before installation.

Certifications:

• No specific certification information provided
