Eaton RD325T56W 2500 Amp Molded Case Circuit Breaker – 3 Pole – 600 V AC – 65 kAIC@480 V – Digitrip 510 RMS LSIG – Series C

The Eaton RD325T56W is a 2500 Amp, 3-pole molded case circuit breaker from the Eaton Series C, R-Frame product range. Designed for commercial and industrial power distribution systems, it features a Digitrip 510 RMS electronic trip unit with LSIG protection, providing Long-Time, Short-Time, Instantaneous, and Ground Fault functions. The breaker is rated for 600 V AC, features bolt-on mounting.

Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Frame: R-Frame
• Catalog Number / MPN: RD325T56W
• Primary Rating: 2500 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600 V AC
• Interrupting Rating: 65 kAIC @ 480 V AC; 50 kAIC @ 600 V AC
• Trip Type: Electronic
• Trip Unit: Digitrip 510 RMS
• Trip Functions: LSIG – Long-Time, Short-Time, Instantaneous, and Ground Fault
• Connection / Mounting: Bolt-On
• Assembly: Complete Breaker

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton
• Catalog Number: RD325T56W
• Series: Series C
• Frame: R-Frame
• Current Rating: 2500 A
• Pole Count: 3 Pole
• Product Type: Electronic Molded Case Circuit Breaker
• Trip Unit: Digitrip 510 RMS
• Trip Functions: LSIG
• UPC:786679216422

Compatibility

The Eaton RD325T56W is intended for compatible Eaton Series C R-Frame power distribution applications, including industrial switchboards, service entrances, and feeder distribution systems.

Certifications

• UL Listed
