Schneider Electric LC1D25P7 TeSys Deca Contactor – 3 Pole – 25A – 230V AC Coil – AC-3 Motor Starter Contactor – DIN Rail/Panel Mount

The Schneider LC1D25P7 is a 3-phase IEC-rated contactor from the TeSys Deca (LC1D) series, designed for motor control and industrial switching applications. It provides reliable performance for controlling electric motors in HVAC systems, pumps, compressors, and automation panels, offering high durability and compact modular design for control cabinets.

Electrical Ratings

• Contact Current Rating (AC-3): 25 A at 440 V
• AC-1 Rated Current: 40 A
• Control Coil Voltage: 230 V AC (50/60 Hz)
• Voltage Rating: up to 690 V AC
• Motor Power Rating:
  • 7.5 HP at 230 V (3-phase)
  • 15 HP at 460 V (3-phase)
  • 20 HP at 575–600 V (3-phase)
• Frequency: 50/60 Hz
• Utilization Category: AC-3 / AC-1

Configuration and Function

• Device Type: IEC Motor Contactor
• Series: TeSys Deca (LC1D Series)
• Poles: 3 Pole (3 NO main contacts)
• Auxiliary Contacts: 1 NO + 1 NC (built-in standard configuration)
• Primary Function: Motor control and power switching
• Operation: Electromagnetic coil-operated switching

Mechanical and Physical Characteristics

• Mounting Type: DIN Rail / Panel Mount
• Terminal Type: Screw clamp terminals
• Compact TeSys D frame design (approx. 45 mm width)
• Enclosure Protection: IP2X (front face)
• Operating Temperature Range: -5 °C to 60 °C
• High mechanical and electrical endurance

Standards and Certifications

• IEC 60947-4-1 compliant
• UL / CSA / CE certified (depending on configuration)
• Manufactured by Schneider Electric / Square D
• GTIN: 3389110349955
• Tariff Code: 85363030
• Country of Origin: France

Features

• Heavy-duty 25A AC-3 motor switching capability
• 230V AC coil for standard industrial control circuits
• High reliability for frequent switching operations
• Built-in auxiliary contacts for control and signaling
• Compact modular design for control panel optimization
• Compatible with TeSys overload relays for motor protection
• Suitable for HVAC, pumps, compressors, conveyors, and automation systems
• Long mechanical life and high switching endurance
• Global industrial standard compliance (IEC design platform)
