Schneider Electric LC1D25T7 Magnetic Contactor – 3 Pole – 25A – 480V AC Coil – TeSys D Series – 3 NO – Non-Reversing IEC Contactor – DIN Rail/Panel Mount

The Schneider Electric LC1D25T7 is a TeSys D series 3-phase IEC magnetic contactor designed for reliable motor control and power switching applications. It is widely used in industrial automation systems, HVAC equipment, pumps, and motor starters, providing high-performance switching with a 480V AC coil and durable electromechanical operation.

Electrical Ratings

• Contact Current Rating (AC-3): 25 A
• AC-1 Rated Current: 40 A
• Control Coil Voltage: 480 V AC (50/60 Hz)
• Voltage Rating: up to 690 V AC
• Motor Power Rating:
  • 7.5 HP at 230 V (3-phase)
  • 15 HP at 460 V (3-phase)
• Frequency: 50/60 Hz
• Utilization Category: AC-3 / AC-1

Configuration and Function

• Device Type: IEC Magnetic Contactor
• Series: TeSys D (LC1D Series)
• Poles: 3 Pole
• Main Contacts: 3 NO (Normally Open)
• Auxiliary Contacts: 1 NO + 1 NC (included)
• Primary Function: Motor control and load switching
• Operation: Electromagnetic coil-driven switching
• Type: Non-reversing contactor

Mechanical and Physical Characteristics

• Mounting Type: DIN Rail / Panel Mount
• Terminal Type: Screw terminals
• Compact TeSys D modular frame design
• Weight: approx. 0.82 lb (0.37 kg)
• Enclosure Protection: IP2X (front face)
• Operating Temperature Range: -5 °C to 60 °C

Standards and Certifications

• IEC 60947-4-1 compliant
• CSA approved
• UL / CE compliant (depending on configuration)
• UNSPSC: 39121500
• Manufacturer: Schneider Electric / Square D

Features

• 25A AC-3 rated industrial motor contactor
• 480V AC coil for industrial control power systems
• High endurance for frequent motor switching
• Built-in 1NO + 1NC auxiliary contacts
• Compact modular TeSys D design for control panels
• Suitable for HVAC, pumps, compressors, and conveyors
• Reliable performance in harsh industrial environments
• Long electrical and mechanical lifespan
• Easy DIN rail or panel mounting installation
