Schneider Electric LC1D40AG7 IEC Contactor – 3 Pole – 40A – 120V AC Coil – TeSys Deca Series – DIN Rail/Panel Mount – Motor Control Contactor – 30 kW / 30 HP

The Schneider Electric LC1D40AG7 is a 3-phase IEC-rated magnetic contactor from the TeSys Deca (LC1D) series, designed for reliable motor control and industrial power switching applications. It is commonly used in motor starters, HVAC systems, pumps, compressors, and automation panels, offering strong switching performance, compact design, and high durability for demanding industrial environments.

Electrical Ratings

• Contact Current Rating: 40 A (AC-3)
• Power Rating: 30 kW (3-phase motors)
• Horsepower Rating: 30 HP
• Control Coil Voltage: 120 V AC
• Voltage Rating: up to 600–690 V AC (series dependent)
• Utilization Category: AC-3 / AC-1
• Frequency: 50/60 Hz

Configuration and Function

• Device Type: IEC Magnetic Contactor
• Series: TeSys Deca (LC1D Series)
• Poles: 3 Pole
• Primary Function: Motor control and load switching
• Operation: Electromagnetic coil-driven switching
• Contact Configuration: 3 NO (Normally Open main contacts)

Mechanical and Physical Characteristics

• Mounting Type: DIN Rail / Panel Mount
• Terminal Type: Screw clamp terminals
• Dimensions: 4.80 in (H) × 2.17 in (W) × 4.72 in (D)
• Operating Temperature Range: -5 °C to 60 °C
• Unit of Measure: Each (EA)
• High mechanical endurance for industrial use

Standards and Certifications

• IEC / UL / CSA compliant design
• UNSPSC: 39120000
• Manufacturer: Schneider Electric
• UPC: 785901732112
• Series: TeSys Deca

Features

• Heavy-duty 40A motor switching capability
• 120V AC control coil for standard industrial systems
• Suitable for 30 kW / 30 HP three-phase motor loads
• Compact TeSys Deca modular design for control panels
• Reliable performance in HVAC, pumps, compressors, and automation systems
• Screw clamp terminals for secure wiring connections
• Wide operating temperature range (-5 °C to 60 °C)
• Long mechanical and electrical service life
• Easy DIN rail or panel mounting integration
