Schneider Electric LC1D65AG7 IEC Contactor – 3 Pole – 65A – 120V AC Coil – TeSys D Series – DIN Rail Mount – Heavy Duty Motor Contactor – Industrial Control Contactor

The Schneider Electric LC1D65AG7 is a high-capacity 3-phase IEC magnetic contactor from the TeSys D (LC1D) series, designed for demanding industrial motor control and power switching applications. It is commonly used in heavy-duty motor starters, HVAC systems, pumps, compressors, and large automation systems, offering strong switching performance, wide certification coverage, and reliable operation in harsh environments.

Electrical Ratings

• Contact Current Rating (AC-3): 65 A
• Voltage Rating: up to 690 V AC / 300 V DC
• Control Coil Voltage: 120 V AC (50/60 Hz)
• Frequency: 50/60 Hz
• Utilization Category: AC-3 / AC-1 (application dependent)
• Application: Three-phase motor and resistive load switching

Configuration and Function

• Device Type: IEC Magnetic Contactor
• Series: TeSys D (LC1D Series)
• Poles: 3 Pole
• Main Contacts: 3 NO (Normally Open)
• Auxiliary Contacts: 1 NO + 1 NC (built-in)
• Primary Function: Motor control and load switching
• Operation: Electromagnetic coil-driven switching
• Action: Non-reversing contactor

Mechanical and Physical Characteristics

• Mounting Type: DIN Rail Mount
• Terminal Type: Screw clamp terminals
• Dimensions: 4.72 in (L) × 2.17 in (W) × 4.8 in (H)
• Operating Temperature Range: -40 °F to 140 °F
• High mechanical durability for industrial use
• Compact TeSys D modular frame design

Standards and Certifications

• IEC / UL / CSA / EN compliant
• CCC, EAC, UKCA certified
• Marine approvals: BV, DNV, GL, LROS, RINA
• RoHS / REACh compliant
• Manufacturer: Schneider Electric
• MPN: LC1D65AG7
• UPC / GTIN: 785901565529

Features

• Heavy-duty 65A AC-3 motor switching capability
• 120V AC coil for industrial control systems
• Built-in 1NO + 1NC auxiliary contacts
• Wide industrial certification for global applications
• Suitable for HVAC, pumps, compressors, and large motor loads
• DIN rail mounting for easy panel integration
• Screw clamp terminals for secure wiring
• High endurance for frequent switching cycles
• Long electrical and mechanical service life
• Reliable TeSys D industrial-grade construction
