Schneider Electric LC1DT40G7 IEC Contactor – 4 Pole – 40A – 120V AC Coil – TeSys D Series – DIN Rail Mount – Multi-Pole Motor Control Contactor

In stock
SKU: LC1DT40G7 GTIN/UPC: 785901503187
$179.20
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Schneider Electric LC1DT40G7 is a 4-pole IEC-rated magnetic contactor from the TeSys D (LC1D) series, designed for reliable switching of motor and auxiliary circuits in industrial control systems. It is commonly used in HVAC systems, motor starters, pumps, compressors, and automation panels where multi-pole switching and high durability are required.

Electrical Ratings

  • Contact Current Rating: 40 A (AC-3)
  • Voltage Rating: up to 690 V AC / 300 V DC
  • Control Coil Voltage: 120 V AC (50/60 Hz)
  • Frequency: 50/60 Hz
  • Utilization Category: AC-3 / AC-1 (application dependent)
  • Application Type: Motor control and multi-circuit switching

Configuration and Function

  • Device Type: IEC Magnetic Contactor
  • Series: TeSys D (LC1D Series)
  • Poles: 4 Pole
  • Main Contacts: 4 NO (or mixed power/control configuration depending on variant)
  • Auxiliary Contacts: 1 NO + 1 NC (base configuration)
  • Primary Function: Motor and multi-circuit load switching
  • Operation: Electromagnetic coil-driven switching
  • Action: Non-reversing contactor

Mechanical and Physical Characteristics

  • Mounting Type: DIN Rail Mount
  • Terminal Type: Screw clamp terminals
  • Frame Type: LC1DT compact industrial design
  • Dimensions: 3.9 in (L) × 1.77 in (W) × 3.58 in (H)
  • Operating Temperature Range: -40 °F to 140 °F
  • High mechanical durability for industrial environments

Standards and Certifications

  • IEC / UL / CSA / EN compliant
  • CCC, EAC, UKCA certified
  • Marine approvals: BV, DNV, GL, LROS, RINA
  • RoHS / REACh compliant
  • Manufacturer: Schneider Electric / Square D
  • MPN: LC1DT40G7
  • UPC / GTIN: 785901503187

Features

  • 40A multi-pole industrial switching capability
  • 120V AC coil for standard industrial control systems
  • 4-pole design for flexible circuit control applications
  • Suitable for HVAC, pumps, compressors, and automation systems
  • Compact TeSys D modular construction for control panels
  • Wide international certifications for global use
  • Screw clamp terminals for secure wiring connections
  • High endurance for frequent switching operations
  • Long electrical and mechanical service life
  • Reliable Schneider Electric industrial-grade performance
  • Type Contactor
  • Vendor Square D
  • Brand Square D
