Schneider Electric LC2D18G7 IEC Reversing Contactor – 3 Pole – 18A – 120V AC Coil – TeSys D Series – DIN Rail Mount – Motor Forward/Reverse Contactor

The Schneider Electric LC2D18G7 is a 3-phase IEC-rated reversing magnetic contactor from the TeSys D (LC2D) series, designed for forward and reverse motor control applications. It is widely used in industrial automation, conveyor systems, hoists, cranes, and machinery where bidirectional motor control is required, offering reliable switching performance and compact panel design.

Electrical Ratings

• Contact Current Rating (AC-3): 18 A
• Voltage Rating: up to 690 V AC / 300 V DC
• Control Coil Voltage: 120 V AC (50/60 Hz)
• Frequency: 50/60 Hz
• Utilization Category: AC-3 / AC-1 (application dependent)
• Application Type: Motor reversing control

Configuration and Function

• Device Type: IEC Reversing Magnetic Contactor
• Series: TeSys D (LC2D Series)
• Poles: 3 Pole
• Main Contacts: 3 NO (per contactor assembly)
• Auxiliary Contacts: 1 NO + 1 NC
• Primary Function: Forward/reverse motor control
• Operation: Electromagnetic coil-driven switching
• Action: Reversing contactor (mechanically/electrically interlocked design)

Mechanical and Physical Characteristics

• Mounting Type: DIN Rail Mount
• Terminal Type: Screw clamp terminals
• Frame Type: LC2D modular reversing assembly
• Dimensions: 3.39 in (L) × 3.54 in (W) × 3.03 in (H)
• Operating Temperature Range: -40 °C to 60 °C
• Compact industrial design for control panels
• High mechanical durability for frequent switching

Standards and Certifications

• IEC / UL / CSA / EN compliant
• CCC, UKCA, EAC certified
• Marine approvals: BV, DNV, GL, LROS, RINA
• RoHS / REACh compliant
• Manufacturer: Schneider Electric / Square D
• MPN: LC2D18G7
• UPC / GTIN: 785901207467

Features

• 18A reversing motor control capability
• 120V AC coil for industrial control systems
• Designed for safe forward/reverse motor operation
• Built-in interlocking for electrical and mechanical safety
• Suitable for conveyors, cranes, hoists, and automation systems
• Compact TeSys D design for efficient panel layout
• Wide international certification coverage
• Screw clamp terminals for secure wiring
• High reliability under frequent switching cycles
• Long electrical and mechanical service life
