Schneider Electric LUCA12FU Control Unit – TeSys Ultra Series – 3–12A – 110–240V Control Voltage – Motor Starter Control Module

The Schneider Electric LUCA12FU is a TeSys Ultra control unit designed for modular motor starter systems. It provides adjustable motor protection and control for small to medium industrial motors. When paired with a compatible TeSys Ultra power base, it delivers a compact, reliable, and efficient motor starter solution for automation and OEM applications.

Electrical Ratings

• Current Rating Range: 3–12 A
• Rated Current: 12 A
• Control Voltage: 110–240 V
• Supply Voltage: up to 600 V AC
• Voltage Rating: 110 V (control reference)
• Power Rating: up to 9 kW
• Phase: 3 Phase (motor starter application)
• Application Type: Motor control and protection module

Configuration and Function

• Device Type: Motor Starter Control Unit
• Series: TeSys Ultra Series
• Primary Function: Motor overload protection and control
• Operation Type: Electronic control module
• Adjustable Current Range: 3–12 A
• Protection Features: Motor overload and protection (system-based function)

Compatibility

• For Use With: TeSys Ultra motor starter power bases
• System Type: Modular motor starter system
• Application: Industrial automation, HVAC, pumps, OEM machinery
• Mounting: Front-mounted control unit

Mechanical and Physical Characteristics

• Dimensions (H × W × D): 2.60 in × 1.77 in × 2.36 in
• Mounting Type: Front mount
• Operating Temperature Range: -25 °C to +70 °C
• Compact modular construction
• Designed for panel space optimization

Controls and Safety Features

• Adjustable current setting (3–12A range)
• Electronic motor protection when paired with compatible base
• Designed for reliable overload protection and motor control
• Stable performance in industrial environments
• Easy installation and replacement in modular systems

Standards and Certifications

• IEC / EN compliant design
• UL / CSA certified (system dependent)
• Manufacturer: Schneider Electric
• Series: TeSys Ultra
• MPN: LUCA12FU
• UPC: 785901221913
• UNSPSC: 39120000
