Schneider Electric TeSys D LC1D25B7 Contactor – 3 Pole – 25A – 24V Coil – 3 NO – AC-3 Motor Control – DIN Rail/Panel Mount

In stock
SKU: LC1D25B7 GTIN/UPC: 785901207122
$99.40
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Schneider Electric LC1D25B7 is a TeSys D series IEC-rated contactor designed for motor control applications in industrial automation and power distribution systems. It provides reliable switching for three-phase motors up to 25A and is suitable for AC-3 utilization duty. Built for durability and high switching frequency, it is commonly used in motor starters, HVAC systems, pumps, and industrial control panels. The unit features a compact 45mm design with DIN rail or screw mounting options for flexible installation.

Electrical Ratings
• Contact Current Rating: 25 A
• Utilization Category: AC-3
• Voltage Rating: up to 690 V AC (AC-3)
• Motor Power Rating: 11 kW at 400 V
• Phase: 3 Phase

Configuration and Function
• Device Type: IEC Motor Contactor
• Series: TeSys D
• Poles: 3 Pole
• Contact Configuration: 3 NO (Normally Open)
• Primary Function: Motor switching and control
• Operation: Electromagnetic coil-operated switching

Coil and Control
• Control Voltage: 24 V AC (50/60 Hz)
• Built-in Auxiliary Contacts: 1 NO + 1 NC
• NC Contact: Mirror certified
• High cycle operation capability up to 3600 cycles/hour

Mechanical and Physical Characteristics
• Mounting Type: DIN Rail or screw fixing
• Width: 45 mm compact design
• Operating Temperature Range: up to 60 °C
• Terminal Type: Screw clamp terminals
• Compact industrial-grade construction for control panels

Standards and Certifications
• IEC compliant (IEC 60947 series)
• UL Listed
• CSA Approved
• CCC, EAC, Marine certified
• RoHS / REACH compliant (Green Premium)

Features

• TeSys D industrial motor contactor for AC-3 duty applications
• 25A switching capacity suitable for medium motor loads
• 24V AC coil for standard industrial control systems
• Integrated 1NO + 1NC auxiliary contacts for control feedback
• High durability for frequent switching operations
• Compact 45mm width saves panel space
• DIN rail or screw mounting flexibility
• Suitable for motors, pumps, compressors, and HVAC systems
• Designed for global industrial environments with multi-standard certification
  • Type Contactor
  • Vendor Square D
  • Brand Square D
