GE SELA36AI0060 Molded Case Circuit Breaker – 60A – 3-Pole – 600V – 65kA @ 480V – Bolt-On – Spectra Series

The GE SELA36AI0060 is a 60A, 3-pole molded case circuit breaker from the GE Spectra Series, Type SELA. It is designed for compatible commercial and industrial electrical distribution applications and features high interrupting capacity, current-limiting performance, and bolt-on mounting.

The breaker provides Instantaneous (I) protection only and is configured as a Mag-Break MCP motor circuit protector, providing magnetic-only protection. It has a 65kA interrupting rating at 480V and a magnetic range of 11–90A. The breaker is UL Listed, suitable for reverse-fed applications, and is supplied without lugs.

Specifications:

• Manufacturer: General Electric (GE)
• Product Type: Molded Case Circuit Breaker
• Catalog No.: SELA36AI0060
• Series: Spectra
• Type: SELA
• Current Rating: 60A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 480V
• Interrupting Capacity: High
• Protection Type: Magnetic Only
• Trip Function: Instantaneous (I) Only
• Trip Type: Mag-Break MCP
• Application: Motor Circuit Protector (MCP)
• Magnetic Range: 11–90A
• Mounting Type: Bolt-On
• Current Limiting: Yes
• Lugs: Not Included
• Reverse Feed: Suitable for Reverse-Fed Applications
• Brand: GE
• Authenticity: Authentic General Electric Product

Part Numbers & Identification:

• Manufacturer Part Number (MPN): SELA36AI0060
• Catalog Number: SELA36AI0060
• Product Family: GE Spectra Series Molded Case Circuit Breakers
• Series: Spectra
• Type: SELA
• Brand: General Electric
• Manufacturer: GE
• Product Type: Molded Case Circuit Breaker
• Model: SELA36AI0060
• Breaker Configuration: 3-Pole, 60A
• Trip Configuration: Mag-Break MCP
• Protection: Magnetic Only
• upc:783164211535

Compatibility:

Designed for use with compatible GE Spectra Series electrical distribution equipment that accepts Type SELA molded case circuit breakers. The SELA36AI0060 is a 60A, 3-pole, 600V Mag-Break MCP with instantaneous magnetic-only protection and is suitable for compatible motor circuit protection applications.

The breaker is suitable for reverse-fed applications and does not include lugs. Always verify the specific panelboard or electrical equipment model, approved breaker type, frame compatibility, system voltage, available fault current, magnetic range, terminal requirements, and reverse-feed suitability before installation.

Certifications:

• UL Listed
• Spectra Series
• 60A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 480V Interrupting Rating
• High Interrupting Capacity
• Current Limiting
• Instantaneous (I) Protection Only
• Magnetic-Only Protection
• Mag-Break MCP
• Bolt-On Mounting
• Suitable for Reverse-Fed Applications
• Lugs Not Included
• Genuine General Electric Product
