GE SELA36AT0100 Molded Case Circuit Breaker – 100A – 3-Pole – 600V AC – 25kAIC – Spectra RMS – Bolt-On/Frame

The GE SELA36AT0100 is a 100A, 3-pole, 600V AC molded case circuit breaker from the Spectra RMS® series, designed for industrial and commercial power distribution applications. It features a solid-state RMS trip system with adjustable short-time and instantaneous protection for overload and short-circuit protection.

The breaker provides high interrupting capacity across multiple voltage levels, including 100kAIC at 240V AC, 65kAIC at 480V AC, and 25kAIC at 600V AC. It is suitable for compatible MCCs, panelboards, and distribution equipment.

Specifications:

• Brand: GE / General Electric
• Manufacturer: General Electric (GE)
• Product Type: Molded Case Circuit Breaker
• Series: Spectra RMS
• Catalog Number: SELA36AT0100
• Current Rating: 100A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V AC
• Interrupting Rating: 100kAIC @ 240V AC; 65kAIC @ 480V AC; 25kAIC @ 600V AC
• Trip Type: Solid-State RMS
• Trip Functions: Adjustable Short-Time and Instantaneous
• Mounting Type: Bolt-On / Frame
• Frequency Rating: 50/60 Hz
• Application: Industrial and commercial power distribution
• Equipment Compatibility: MCCs, panelboards, and distribution equipment
• Protection: Overload and short-circuit protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): SELA36AT0100
• Catalog Number: SELA36AT0100
• Product Family: Spectra RMS Molded Case Circuit Breakers
• Brand: GE
• Manufacturer: General Electric
• Product Type: Molded Case Circuit Breaker
• Frame: Spectra RMS
• UPC / GTIN: 783164211474
• Additional GTIN: 0783164211474 / 0724165932128
• UPC:783164211474

Compatibility:

Designed for use with compatible GE Spectra RMS MCCs, panelboards, and electrical distribution equipment accepting the specified breaker configuration. The SELA36AT0100 is suitable for 3-phase, 100A, 600V AC applications and provides solid-state RMS protection with adjustable short-time and instantaneous functions.

Always verify the specific equipment model, frame compatibility, mounting configuration, voltage, interrupting rating, and trip-unit requirements before installation.

Certifications:

• UL Listed
• CSA Certified
• UL 489
• CSA C22.2
• IEC 60947-2
• Spectra RMS Series
