Siemens SHND69120ANTH 1200 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 65 kA@480 V – High Interrupting Capacity – Electronic LSI Trip – 100% Rated – Bolt-On – Sentron Series

The Siemens SHND69120ANTH is a 1200 Amp, 3-pole, 3-phase molded case circuit breaker from the Siemens Sentron Series, Type SHND. It is rated for 600 V and features high interrupting capacity.

The breaker incorporates a digital solid-state electronic trip system with LSI (Long-Time, Short-Time, and Instantaneous) trip functions for circuit protection. It is 100% rated and designed for bolt-on mounting. The breaker is suitable for reverse-connection applications.

The supplied product information lists both 35 kA and 65 kA interrupting ratings at 480 V. These conflicting ratings require confirmation against Siemens manufacturer documentation.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Molded Case Circuit Breaker
• Series: Sentron
• Type: SHND
• Catalog Number / MPN: SHND69120ANTH
• Primary Rating: 1200 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating at 480 V: 35 kA / 65 kA (Conflicting Supplied Values)
• Interrupting Capacity: High
• Trip Type: Digital Solid-State Electronic
• Trip Functions: LSI – Long-Time, Short-Time, and Instantaneous
• Continuous Current Rating: 100% Rated
• Connection / Mounting: Bolt-On
• Reverse-Connection Suitability: Acceptable for Reverse-Connection Applications

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: SHND69120ANTH
• Series: Sentron
• Type: SHND
• Current Rating: 1200 A
• Pole Count: 3 Pole
• Phase Configuration: 3 Phase
• Product Type: Electronic Molded Case Circuit Breaker
• Trip Mechanism: Digital Solid-State Electronic
• Trip Functions: LSI – Long-Time, Short-Time, and Instantaneous
• Continuous Rating: 100%
• Mounting Type: Bolt-On
• UPC:783643253179

Compatibility

The Siemens SHND69120ANTH is intended for compatible Siemens Sentron Series electrical distribution equipment supporting Type SHND, 1200 Amp, 3-pole bolt-on molded case circuit breakers, including acceptable reverse-connection applications.
