Siemens 3VA4160-4ED14-0AA0 60A 1P Molded Case Circuit Breaker – Bolt-On – 120/277V AC

The Siemens 3VA4160-4ED14-0AA0 is a 60A, 1-pole molded case circuit breaker from the SENTRON 3VA4 series, designed specifically for commercial power distribution systems using Siemens P1 panelboards. Featuring proven thermal-magnetic trip technology with LI (Long-Time and Instantaneous) protection, it delivers dependable overload and short-circuit protection for branch circuit applications.

This HACR-rated breaker offers exceptional fault-clearing performance with interrupting capacities up to 85kA at 120VAC. It serves as a direct replacement for discontinued Siemens ED61B060 and HED41B060 breakers, making it an ideal solution for facility upgrades and retrofit projects.

Electrical Ratings

• Current Rating: 60 Amps
• Voltage Ratings:
  • 120 VAC
  • 277 VAC
  • 125 VDC
  • 347 VAC
• Number of Poles: 1-Pole
• Phase: 1-Phase
• Interrupting Capacity:
  • 85 kA @ 120 VAC
  • 35 kA @ 277 VAC
  • 85 kA @ 125 VDC
  • 18 kA @ 347 VAC

Trip & Protection Features

• Trip Technology: Thermal-Magnetic
• Trip Function Code: LI
• Protection Functions:
  • Long-Time Protection
  • Instantaneous Protection
• Trip Adjustability:
  • Fixed Thermal
  • Fixed Magnetic
• HACR Rated: Yes
• Reverse Feed Capable: Yes

Key Specifications

• Brand: Siemens
• Series: 3VA4
• Mounting Style: Bolt-On
• Terminal Type: Lugs
• Accessories Included: Load Side Lugs (Factory Installed)

Compatibility

• Siemens P1 Panelboards

Wiring Details

• Wire Gauge Range: 14 AWG – 3/0 AWG (Cu/Al)
• Minimum Wire Size: 14 AWG
• Maximum Wire Size: 3/0 AWG

Available Options

• Shunt Trip
• Auxiliary Switch
• Undervoltage Release
• Alarm Switch
• Padlock Attachment

Standards & Approvals

• UL 489
• IEC 60947-2
• CSA C22.2 No. 5
• CE Approved
• CSA Approved
• HACR Rated
• UL Listed
• Temperature Rating: -25°C to 70°C

Construction Features

• HACR Rated
• Reverse Feed Capability
• Thermal-Magnetic Protection
• Commercial-Duty Construction

Applications

• Commercial electrical distribution
• Branch circuit protection
• Siemens P1 panelboard installations
• Retrofit replacement for Siemens ED61B060 and HED41B060 breakers
• HVAC and air-conditioning equipment protection (HACR applications)
