Siemens 3VA4195-4ED14-0AA0 15A 1P Molded Case Circuit Breaker – Bolt-On – 277V AC

The Siemens 3VA4195-4ED14-0AA0 is a 15A, 1-pole molded case circuit breaker from the SENTRON 3VA4 series, designed for commercial and light industrial electrical distribution systems. It features a TM210 thermal-magnetic trip unit with fixed thermal and fixed magnetic (FTFM) protection, providing reliable long-time and instantaneous overcurrent protection.

Built on the 3VA41 frame with Standard (Class S) breaking capacity, this breaker delivers dependable fault protection with interrupting performance suited for branch circuit applications in panelboard installations.

Electrical Ratings

• Current Rating: 15 Amps
• Voltage Rating: 277V AC
• Number of Poles: 1-Pole
• Interrupting Capacity:
  • 25 kA @ 277V AC
  • 14 kA @ 600Y/347V AC
• Frame Size: 3VA41

Trip & Protection Features

• Trip Unit: TM210
• Protection Type: Thermal-Magnetic
• Functions: FTFM (Fixed Thermal, Fixed Magnetic)
• Overload Protection (Ir): 15A, Permanently Set
• Short-Circuit Protection (Ii): 10 × In
• Application: Line Protection

Key Specifications

• Brand: Siemens
• Series: 3VA4
• Family: 3VA
• Part Number: 3VA4195-4ED14-0AA0
• Category: Molded Case Circuit Breaker
• Mounting Type: Bolt-On
• Terminal Type: Load-Side Lugs Installed

Standards & Certifications

• CSA Approved

Physical Characteristics

• Weight: 0.617 lb
• Dimensions (W × H × D): 1 × 5.5 × 3.7 in

Applications

• Commercial lighting and branch circuits
• Panelboard installations
• Light industrial electrical systems
• Overcurrent protection for 277V circuits
• Retrofit replacement applications within Siemens 3VA4 systems
