Siemens 3VA5111-6ED31-0AA0 110A 3P Molded Case Circuit Breaker – Feed-Thru – 480V AC

In stock
SKU: 3VA5111-6ED31-0AA0 GTIN/UPC: 804766301025
$828.90
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5111-6ED31-0AA0 is a 110A, 3-pole molded case circuit breaker from the SENTRON 3VA5 series, designed for industrial and commercial power distribution systems. It features a TM210 thermal-magnetic trip unit with fixed thermal and fixed magnetic (FTFM) protection, delivering reliable long-time and instantaneous overcurrent protection.

Built on a 3VA5 UL Frame 125 with High (Class H) breaking capacity, this breaker is suitable for feeder and branch circuit applications in panelboards and switchboards. Its feed-through configuration and “without connection” (no lugs supplied) design allow flexible field installation depending on system requirements.

Electrical Ratings

  • Current Rating: 110 Amps
  • Voltage Rating: 480 VAC (also applicable in 600Y/347 VAC systems)
  • Number of Poles: 3-Pole
  • Phase: 3-Phase
  • Interrupting Capacity:
    • 100 kA @ 480 VAC
  • Frame Size: 125A frame class
  • Breaking Capacity Class: H (High)

Trip & Protection Features

  • Trip Unit: TM210
  • Protection Type: Thermal-Magnetic (FTFM)
  • Functions: LI (Long-Time, Instantaneous)
  • Overload Protection (Ir): 110A, permanently set
  • Short-Circuit Protection (Ii): 10 × In, fixed
  • Trip Technology: Solid-state referenced configuration (as per listing)
  • Connection Type: Feed-through (no lugs included)

Key Specifications

  • Brand: Siemens
  • Series: 3VA5
  • Part Number: 3VA5111-6ED31-0AA0
  • Category: Molded Case Circuit Breaker
  • Mounting Style: Panelboard / switchboard dependent installation
  • Terminal Type: None (field-dependent connection)

Standards & Certifications

  • CSA Approved
  • UL Listed (per 3VA5 platform standards)

Physical Characteristics

  • Weight: 2.0 lb

Applications

  • Industrial and commercial power distribution
  • Feeder and branch circuit protection
  • Panelboard and switchboard systems
  • High fault level environments requiring Class H interrupting capacity
  • Retrofit or configurable feed-through installations
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
