Siemens 3VA5130-4ED31-0AA0 30 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480Y-277/600Y-347VAC & 500VDC

In stock
SKU: 3VA5130-4ED31-0AA0 GTIN/UPC: 804766300462
$404.60
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5130-4ED31-0AA0 is a high-performance molded case circuit breaker (MCCB) engineered for demanding commercial and industrial power distribution applications. As part of the Siemens 3VA5 series, this 3-pole, 30A circuit breaker provides dependable overcurrent and short-circuit protection through its TM210 thermal-magnetic trip unit with fixed long-time and instantaneous (LI) protection settings. Designed for installation in Siemens 3VA panelboards and Siemens P1 panelboards with the appropriate mounting kit, it also serves as the designated replacement for the discontinued ED63B030 breaker. Featuring Class S breaking capacity, current-limiting performance, HACR certification, and HID suitability, this breaker delivers reliable protection in a wide range of electrical systems.

Voltage and Rating

  • Current Rating: 30 Amps
  • Voltage Rating: 240VAC, 480Y/277VAC, 600Y/347VAC, 500VDC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 65kA @ 240VAC
    • 25kA @ 480Y/277VAC
    • 14kA @ 600Y/347VAC
    • 50kA @ 500VDC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: 3VA5
  • Number of Poles: 3-Pole
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs
  • Trip Technology: Thermal Magnetic
  • Trip Function Code: LI
  • Trip Function: Long-Time and Instantaneous Protection
  • Trip Adjustability: Fixed Thermal, Fixed Magnetic
  • For Use With: Siemens 3VA Panelboards and Siemens P1 Panelboards (requires mounting kit)

Technical Specifications

  • Construction Features: HACR Rated, Current Limiting, Class S Breaking Capacity, HID Rated
  • Temperature Rating: -25°C to 70°C
  • Accessories Included: None (0AA0 configuration)
  • Available Options: Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Handle Lock, Padlock Attachment

Standards and Approvals

  • Standards: HACR, IEC 60947-2, UL 489
  • Approvals: CE, CSA, EAC, UL, VDE

Product Data

  • Manufacturer: Siemens
  • Series: 3VA5
  • Part Number: 3VA5130-4ED31-0AA0

Applications

  • Commercial Power Distribution Systems
  • Industrial Electrical Installations
  • Panelboards and Switchboards
  • Feeder and Branch Circuit Protection
  • HVAC Equipment Protection (HACR Applications)
  • HID Lighting Circuits
  • High Fault Current Electrical Systems
  • Replacement of Siemens ED63B030 Circuit Breakers
  • Type Circuit Breakers
