Siemens 3VA5140-5ED31-0AA0 40 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600Y-347VAC & 500VDC

The Siemens 3VA5140-5ED31-0AA0 is a high-performance molded case circuit breaker from the advanced SENTRON 3VA5 frame family, designed for demanding commercial and industrial power distribution systems. This 3-pole, 40A breaker provides reliable long-time and instantaneous protection using a thermal-magnetic trip unit with fixed Ir and Ii settings. Engineered as a modern replacement for legacy ED63B040 breakers, it integrates seamlessly into Siemens 3VA panelboards and switchboards. With Class M breaking capacity and high interrupting performance, it ensures dependable fault protection for heavy-duty electrical loads.

Voltage and Rating

• Current Rating: 40 Amps
• Voltage Rating: 240VAC, 480VAC, 600Y/347VAC, 500VDC
• Phase: 3-Phase
• Frequency: 50/60 Hz
• AIC Rating:
  • 85kA @ 240VAC
  • 35kA @ 480VAC
  • 18kA @ 600Y/347VAC
  • 85kA @ 500VDC

Key Specifications

• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Series: 3VA5
• Number of Poles: 3-Pole
• Mounting Style: Panel Mount
• Terminal Type: Lugs
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time and Instantaneous Protection
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Breaking Capacity Class: Class M
• For Use With: Siemens 3VA Panelboards and Switchboards

Technical Specifications

• Protection Features: Overload and Short-Circuit Protection
• Construction Features: HACR Rated, HID Rated, Reverse Feed
• Temperature Rating: -25°C to 70°C
• Accessories Included: Nut Keeper
• Available Options: Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Motor Operator, Lug Kits, DIN Rail Adapter

Standards and Approvals

• Standards: CSA C22.2 No. 5, IEC 60947-2, UL 489
• Approvals: ABS, CCC, CE, CSA, DNV, EAC, Lloyd’s Register, UL, VDE

Product Data

• Manufacturer: Siemens
• Series: 3VA5
• Part Number: 3VA5140-5ED31-0AA0

Applications

• Industrial Power Distribution Systems
• Commercial Electrical Installations
• Switchboards and Panelboards
• Heavy-Duty Load Protection
• Feeder and Branch Circuit Protection
• HVAC and Motor Load Applications
