Siemens 3VA5160-4ED21-0AA0 60 Amp 2-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600Y-347VAC & 250VDC

The Siemens 3VA5160-4ED21-0AA0 is a compact and versatile molded case circuit breaker (MCCB) designed for commercial and industrial power distribution applications. Built on the 125A SENTRON 3VA51 frame, this 2-pole, 60A breaker maximizes panel space while delivering dependable overcurrent and short-circuit protection. Equipped with a thermal-magnetic trip unit featuring fixed long-time and instantaneous (LI) protection settings, it provides reliable circuit protection for a wide range of electrical systems. The breaker is designed for installation in Siemens P1, P2, and P3 panelboards, SB switchboards, and motor control centers, and serves as a direct replacement for legacy ED62B060 breakers.

Voltage and Rating

• Current Rating: 60 Amps
• Voltage Rating: 240VAC, 480VAC, 600Y/347VAC, 250VDC
• Phase: Single Phase
• Frequency: 50/60 Hz
• AIC Rating:
  • 65kA @ 240VAC
  • 25kA @ 480VAC
  • 14kA @ 600Y/347VAC
  • 50kA @ 250VDC

Key Specifications

• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Series: SENTRON 3VA5
• Part Number: 3VA5160-4ED21-0AA0
• Frame Size: 125A (3VA51 Frame)
• Number of Poles: 2-Pole
• Mounting Style: Panel Mount
• Terminal Type: Lugs
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time and Instantaneous Protection
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• For Use With: Siemens P1, P2, P3 Panelboards, SB Switchboards, and Motor Control Centers

Technical Specifications

• Construction Features: HACR Rated, Current Limiting, Reverse Feed
• Temperature Rating: -25°C to 70°C
• Accessories Included: None (No Lugs Included)
• Available Options: Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Motor Operator, Handle Lock, Padlock Attachment, DIN Rail Adapter, Busbar System

Standards and Approvals

• Standards: IEC 60947-2, UL 489, HACR
• Approvals: ABS, CE, CSA, EAC, UL, VDE

Product Data

• Manufacturer: Siemens
• Series: 3VA5
• Part Number: 3VA5160-4ED21-0AA0

Applications

• Commercial Power Distribution Systems
• Industrial Electrical Installations
• Panelboards and Switchboards
• Motor Control Centers
• Feeder and Branch Circuit Protection
• HVAC Equipment Protection (HACR Applications)
• Current-Limiting Protection Systems
• Replacement of Siemens ED62B060 Circuit Breakers
