Siemens 3VA5160-5ED31-0AA0 60 Amp 3-Pole Molded Case Circuit Breaker – Feed-Thru Mount – 600V AC

In stock
SKU: 3VA5160-5ED31-0AA0 GTIN/UPC: 804766300745
$415.80
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5160-5ED31-0AA0 is a low-voltage molded case circuit breaker (MCCB) designed to provide dependable overcurrent and short-circuit protection in commercial and industrial electrical distribution systems. Part of the Siemens 3VA51 frame series, this 3-pole, 60A breaker features a TM210 thermal-magnetic trip unit with fixed long-time (Ir) and instantaneous (Ii) protection settings for reliable circuit performance. Built with Medium (Class M) breaking capacity, it offers interrupting ratings of 35kA at 480VAC and 18kA at 600Y/347VAC. Supplied without lugs, the breaker combines compact dimensions with robust protection, making it suitable for panelboard, switchboard, and power distribution applications.

Voltage and Rating

  • Current Rating: 60 Amps
  • Voltage Rating: 600 Volts AC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 100kA @ 480VAC
    • 35kA @ 480VAC (Class M)
    • 18kA @ 600Y/347VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: 3VA51
  • Family: 3VA
  • Type: 3VA
  • Number of Poles: 3-Pole
  • Protection Type: Solid State / Thermal-Magnetic
  • Trip Unit: TM210 Thermal-Magnetic Trip Unit
  • Trip Function: Long-Time and Instantaneous Protection
  • Trip Adjustability: Fixed Ir, Fixed Ii
  • Connection Type: Without Lugs
  • Category: Molded Case Breakers

Technical Specifications

  • Breaking Capacity Class: Medium (Class M)
  • Protection Features: Overload and Short-Circuit Protection
  • Construction: Compact Molded Case Design
  • Frame Size: 3VA51 Frame

Standards and Approvals

  • Certification: CSA Approved

Product Data

  • Manufacturer: Siemens
  • Part Number: 3VA5160-5ED31-0AA0
  • Family: 3VA

Dimensions and Weight

  • Width: 3.0 in
  • Height: 5.5 in
  • Depth: 3.7 in
  • Weight: 2.072 lbs

Applications

  • Commercial Power Distribution Systems
  • Industrial Electrical Installations
  • Panelboards and Switchboards
  • Feeder Circuit Protection
  • Branch Circuit Protection
  • Equipment and Machinery Protection
  • Motor Control Applications
  • Low-Voltage Distribution Networks
  • High Fault Current Environments
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
