Siemens 3VA5160-6EC31-0AA0 60 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600Y-347VAC & 500VDC

The Siemens 3VA5160-6EC31-0AA0 is a high-performance molded case circuit breaker (MCCB) engineered for demanding industrial and commercial power distribution applications. Part of the SENTRON 3VA5 series, this 3-pole, 60A breaker provides dependable long-time and instantaneous (LI) protection through its TM230 thermal-magnetic trip unit. Featuring fixed thermal protection and adjustable magnetic settings, it offers enhanced flexibility for coordinating protection with system requirements. Designed for installation in Siemens 3VA panelboards, Siemens P1 panelboards (with adapter), and switchboards, it serves as a direct replacement for legacy HHED63B060 and HED43B060 circuit breakers. With a high interrupting capacity of 65kA at 480VAC, HACR certification, HID suitability, and reverse-feed capability, this breaker delivers reliable fault protection for critical electrical systems.

Voltage and Rating

• Current Rating: 60 Amps
• Voltage Rating: 240VAC, 480VAC, 600Y/347VAC, 500VDC
• Phase: 3-Phase
• Frequency: 50/60 Hz
• AIC Rating:
  • 100kA @ 240VAC
  • 65kA @ 480VAC
  • 25kA @ 600Y/347VAC
  • 100kA @ 500VDC

Key Specifications

• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Series: SENTRON 3VA5
• Part Number: 3VA5160-6EC31-0AA0
• Number of Poles: 3-Pole
• Mounting Style: Panel Mount
• Terminal Type: Lugs
• Trip Technology: Thermal Magnetic
• Trip Unit: TM230
• Trip Function Code: LI
• Trip Function: Long-Time and Instantaneous Protection
• Trip Adjustability: Fixed Thermal, Adjustable Magnetic
• For Use With: Siemens 3VA Panelboards, Siemens P1 Panelboards (with adapter), and Switchboards

Technical Specifications

• Construction Features: HACR Rated, HID Rated, Reverse Feed
• Temperature Rating: -25°C to 70°C
• Accessories Included: Nut Keeper Plate
• Available Options: Auxiliary Switch, Shunt Trip, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator

Standards and Approvals

• Standards: IEC 60947-2, UL 489
• Approvals: CE, CSA, UL, VDE

Product Data

• Manufacturer: Siemens
• Series: 3VA5
• Part Number: 3VA5160-6EC31-0AA0

Applications

• Industrial Power Distribution Systems
• Commercial Electrical Installations
• Siemens 3VA and P1 Panelboards
• Switchboards
• Feeder and Branch Circuit Protection
• HVAC Equipment Protection (HACR Applications)
• HID Lighting Systems
• High Fault Current Environments
• Replacement of Siemens HHED63B060 and HED43B060 Circuit Breakers
