Siemens 3VA5160-6ED31-0AA0 60 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600Y-347VAC & 500VDC

In stock
SKU: 3VA5160-6ED31-0AA0 GTIN/UPC: 804766300721
$512.40
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5160-6ED31-0AA0 is a high-performance molded case circuit breaker (MCCB) designed for reliable protection in three-phase commercial and industrial power distribution systems. As part of the SENTRON 3VA5 series, this 3-pole, 60A breaker utilizes a TM210 thermal-magnetic trip unit to provide dependable long-time and instantaneous (LI) protection against overloads and short circuits. Designed for installation in Siemens P1, P2, and P3 panelboards, SB switchboards, and motor control centers, it serves as a direct replacement for legacy HHED63B060 breakers. Featuring current-limiting technology, reverse-feed capability, HACR certification, and a high interrupting capacity of 65kA at 480VAC, this breaker delivers robust protection for demanding electrical applications.

Voltage and Rating

  • Current Rating: 60 Amps
  • Voltage Rating: 240VAC, 480VAC, 600Y/347VAC, 500VDC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 100kA @ 240VAC
    • 65kA @ 480VAC
    • 25kA @ 600Y/347VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: SENTRON 3VA5
  • Number of Poles: 3-Pole
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs
  • Trip Technology: Thermal Magnetic
  • Trip Unit: TM210
  • Trip Function Code: LI
  • Trip Function: Long-Time and Instantaneous Protection
  • Trip Adjustability: Fixed Thermal, Fixed Magnetic
  • For Use With: Siemens P1, P2, P3 Panelboards, SB Switchboards, and Motor Control Centers

Technical Specifications

  • Construction Features: HACR Rated, Current Limiting, Reverse Feed
  • Temperature Rating: -25°C to 70°C
  • Accessories Included: None (No Lugs Included)
  • Available Options: Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Motor Operator, Handle Lock, Padlock Attachment, DIN Rail Adapter, Busbar System

Standards and Approvals

  • Standards: IEC 60947-2, UL 489, HACR Rated
  • Approvals: ABS, CE, CSA, EAC, IEC, UL, VDE

Product Data

  • Manufacturer: Siemens
  • Series: 3VA5
  • Part Number: 3VA5160-6ED31-0AA0

Applications

  • Three-Phase Power Distribution Systems
  • Commercial Electrical Installations
  • Industrial Power Distribution
  • Panelboards and Switchboards
  • Motor Control Centers
  • Feeder and Branch Circuit Protection
  • HVAC Equipment Protection (HACR Applications)
  • Current-Limiting Protection Systems
  • Replacement of Siemens HHED63B060 Circuit Breakers
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
