Siemens / ITE

Siemens 3VA5170-4EC31-0AA0 70 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600Y-347VAC & 500VDC

In stock
SKU: 3VA5170-4EC31-0AA0 GTIN/UPC: 804766300837
$544.60
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5170-4EC31-0AA0 is a robust molded case circuit breaker (MCCB) engineered for commercial and industrial power distribution systems. Built on the compact 3VA51 frame, this 3-pole, 70A breaker provides dependable overload and short-circuit protection through its TM230 thermal-magnetic trip unit. Featuring fixed thermal protection and adjustable magnetic protection, it allows for improved coordination with downstream devices while maintaining reliable fault-clearing performance. Designed for installation in Siemens P1, P2, and P3 panelboards, SB switchboards, and motor control centers, it serves as a direct replacement for legacy ED63B070 circuit breakers. Its current-limiting design, HACR rating, and reverse-feed capability make it an excellent choice for demanding electrical applications.

Voltage and Rating

  • Current Rating: 70 Amps
  • Voltage Rating: 240VAC, 480VAC, 600Y/347VAC, 500VDC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 65kA @ 240VAC
    • 25kA @ 480VAC
    • 14kA @ 600Y/347VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: 3VA5
  • Frame Size: 3VA51
  • Number of Poles: 3-Pole
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs
  • Trip Technology: Thermal Magnetic
  • Trip Unit: TM230
  • Trip Function Code: LI
  • Trip Function: Long-Time and Instantaneous Protection
  • Trip Adjustability: Fixed Thermal, Adjustable Magnetic
  • For Use With: Siemens P1, P2, P3 Panelboards, SB Switchboards, and Motor Control Centers

Technical Specifications

  • Construction Features: HACR Rated, Current Limiting, Reverse Feed
  • Temperature Rating: -25°C to 70°C
  • Accessories Included: None (Without Connection)
  • Available Options: Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Motor Operator, Handle Lock, Padlock Attachment, DIN Rail Adapter, Busbar System

Standards and Approvals

  • Standards: IEC 60947-2, UL 489
  • Approvals: CE, CSA, EAC, IEC, UL, VDE

Product Data

  • Manufacturer: Siemens
  • Series: 3VA5
  • Part Number: 3VA5170-4EC31-0AA0

Applications

  • Commercial Power Distribution Systems
  • Industrial Electrical Installations
  • Siemens P1, P2, and P3 Panelboards
  • SB Switchboards
  • Motor Control Centers
  • Feeder and Branch Circuit Protection
  • HVAC Equipment Protection (HACR Applications)
  • Current-Limiting Protection Systems
  • Replacement of Siemens ED63B070 Circuit Breakers
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
