Siemens / ITE

Siemens 3VA5180-5ED31-0AA0 80 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600Y-347VAC

In stock
SKU: 3VA5180-5ED31-0AA0 GTIN/UPC: 804766300868
$593.60
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5180-5ED31-0AA0 is a heavy-duty molded case circuit breaker (MCCB) from the SENTRON 3VA5 series, engineered for commercial and industrial power distribution systems. This 3-pole, 80A breaker utilizes a thermal-magnetic trip unit with fixed long-time and instantaneous (LI) protection to provide dependable overload and short-circuit protection. Designed for installation in Siemens P1, P2, P3, P4, and P5 panelboards, switchboards, and motor control centers, it also serves as a replacement for legacy ED43B080 breakers when used with the appropriate mounting kit. Featuring a medium Class M breaking capacity of 35kA at 480VAC, current-limiting performance, and HACR certification, this breaker is ideal for demanding electrical applications.

Voltage and Rating

  • Current Rating: 80 Amps
  • Voltage Rating: 240VAC, 480VAC, 600Y/347VAC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 85kA @ 240VAC
    • 35kA @ 480VAC
    • 18kA @ 600Y/347VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: SENTRON 3VA5
  • Part Number: 3VA5180-5ED31-0AA0
  • Number of Poles: 3-Pole
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs
  • Trip Technology: Thermal Magnetic
  • Trip Function Code: LI
  • Trip Function: Long-Time and Instantaneous Protection
  • Trip Adjustability: Fixed Thermal, Fixed Magnetic
  • For Use With: Siemens P1, P2, P3, P4, P5 Panelboards, Switchboards, and Motor Control Centers

Technical Specifications

  • Breaking Capacity Class: Class M
  • Construction Features: HACR Rated, Current Limiting
  • Temperature Rating: -25°C to 70°C
  • Accessories Included: Nut Keepers
  • Available Options: Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Lugs, Motor Operator
  • Lugs Included: No

Standards and Approvals

  • Standards: IEC 60947-2, UL 489, HACR
  • Approvals: ABS, CE, CSA, cULus, DNV, EAC, IEC, Lloyd's Register, UL

Product Data

  • Manufacturer: Siemens
  • Series: 3VA5
  • Part Number: 3VA5180-5ED31-0AA0

Applications

  • Commercial Power Distribution Systems
  • Industrial Electrical Installations
  • Panelboards and Switchboards
  • Motor Control Centers
  • Feeder and Branch Circuit Protection
  • HVAC Equipment Protection (HACR Applications)
  • Current-Limiting Protection Systems
  • High Fault Current Environments
  • Replacement of Siemens ED43B080 Circuit Breakers
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
