Siemens 3VA5210-5EC61-0AA0 100 Amp 2-Pole Molded Case Circuit Breaker – Panel Mount – 600V AC

The Siemens 3VA5210-5EC61-0AA0 is a heavy-duty molded case circuit breaker (MCCB) from the SENTRON 3VA series, engineered for commercial and industrial power distribution applications. Built on the larger 3VA52 frame, this 100A, 2-pole breaker features a TM230 thermal-magnetic trip unit that provides dependable long-time and instantaneous (LI) protection. The breaker incorporates fixed overload protection (Ir) and adjustable instantaneous magnetic protection (Ii), allowing improved coordination with downstream devices. Designed with Medium (Class M) breaking capacity, it delivers reliable fault interruption up to 35kA at 480VAC and 18kA at 600VAC. Supplied without lugs, this breaker is ideal for panelboard, switchboard, and feeder protection applications requiring robust circuit protection.

Voltage and Rating

• Current Rating: 100 Amps
• Voltage Rating: 600 Volts AC
• Phase: 3-Phase
• Frequency: 50/60 Hz
• AIC Rating:
  • 100kA @ 480VAC
  • 35kA @ 480VAC (Class M)
  • 18kA @ 600VAC

Key Specifications

• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Series: SENTRON Series
• Part Number: 3VA5210-5EC61-0AA0
• Frame Size: 3VA52 Frame
• Number of Poles: 2-Pole
• Configuration: 2(3)-Pole
• Mounting Style: Panel Mount
• Trip Technology: Thermal Magnetic
• Trip Unit: TM230
• Trip Function: Long-Time and Instantaneous Protection (LI)
• Trip Adjustability: Fixed Ir, Adjustable Ii
• Protection Type: Solid State
• Connection Type: Without Lugs

Technical Specifications

• Breaking Capacity Class: Medium (Class M)
• Overload Protection: 100A Fixed (Ir)
• Instantaneous Protection: Adjustable Magnetic Trip (Ii)
• Construction: Compact Molded Case Design
• Application: Commercial and Industrial Power Distribution

Standards and Approvals

• Certification: CSA Approved

Product Data

• Manufacturer: Siemens
• Series: SENTRON
• Part Number: 3VA5210-5EC61-0AA0
• Family: 3VA

Dimensions and Weight

• Width: 4.1 in
• Height: 7.3 in
• Depth: 4.2 in
• Weight: 4.189 lbs

Applications

• Commercial Power Distribution Systems
• Industrial Electrical Installations
• Panelboards and Switchboards
• Feeder Circuit Protection
• Branch Circuit Protection
• Equipment and Machinery Protection
• Motor Control Applications
• Low-Voltage Distribution Networks
• High Fault Current Environments
• Current-Limiting Protection Systems
